Technical Specifications
| Parameter | Specification |
|---|---|
| Model | SNB10D-225/CU2T |
| Mounting Type | Rack Mountable (19-inch rack, M5 screws with insulating bushings) |
| Power Supply Voltage | 220 to 240 V AC, 50/60 Hz |
| Power Consumption | 230 VA |
| Power Supply Configuration | Dual-redundant power supply (R4.01 or later) |
| Connector Unit | /CU2T – Connector Unit with Terminator for ESB Bus (Part number: S9343FA) |
| Bus Interface Modules | Two SSB401 ESB bus interface modules |
| Supported Control Units | Up to 13 units with SEC402 or up to 9 units with SEC401 |
| Weight | Approx. 5.9 kg |
| Dimensions (W x H x D) | 482.6 × 221.5 × 205 mm |
| Environmental Standard | ISA Standard G3 (-20 to 70°C), with explosion protection |
| Standards Compliance | Refer to “ProSafe-RS Standards Compliant Models” (GS 32P01B60-01EN) |
| Modules Included | Power Supply Modules ×2, ESB Interface Modules ×2 |
| Accessories Included | Insulating bushings ×4 |
| Recommended Cable | YCB301 ESB bus cable (minimum 1 m length) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the SNB10D-225/CU2T Safety Node Unit?
A1: The SNB10D-225/CU2T acts as an interface for transmitting analog and contact signals from the field to the safety control unit via the ESB bus, and also supplies power to the I/O modules.
Q2: What is the difference between the /CU2N and /CU2T options?
A2: The /CU2T option includes a terminator for the ESB bus, while the /CU2N does not. /CU2T is typically used for terminating the bus at the end of the communication line.
Q3: How many SNB10D units can be connected to one safety control unit?
A3: Up to 13 SNB10D units can be connected when using the SEC402 ESB bus coupler module, or up to 9 units when using the SEC401.
Q4: What are the installation requirements for this unit?
A4: The SNB10D-225/CU2T must be rack mounted using four M5 screws and insulating bushings. It should be installed in a keyed metallic cabinet to comply with safety, EMC, and explosion protection standards.
Q5: What is the operating temperature range of the SNB10D-225/CU2T?
A5: The operating temperature range is from -20°C to +70°C, complying with ISA Standard G3.
Q6: What kind of power supply does this model support?
A6: This model supports 220 to 240 V AC power supply with dual-redundant power configuration.
Q7: Is a dummy cover required for unused I/O slots?
A7: Yes, any unused I/O module slots must be covered using the SDCV01 dummy cover to ensure proper operation and protection.
Q8: What is the total weight and physical size of the unit?
A8: The SNB10D-225/CU2T weighs approximately 5.9 kg and has dimensions of 482.6 mm (W) × 221.5 mm (H) × 205 mm (D).
