Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Contact Output Module |
| Number of Points | 16 points |
| Signal Type | Transistor contact |
| Output Rating | 30 V DC, 100 mA or lower |
| Pulse Width | 8 ms to 7200 s |
| Pulse Width Resolution | 8 ms (Max. 1 ms delay) |
| Current Consumption | 130 mA (24 V DC) |
| Signal Isolation | Isolated channels |
| Signal Connection | ADT16 (KS2 or KS3 cable) |
| Weight | 0.3 kg |
| Dimensions | 120 x 100 x 60 mm |
FAQ
FAQ
Q1: What is the function of the ADM51-2 Contact Output Module?
A1: The ADM51-2 module is used to provide contact outputs for controlling external devices, with isolation and a wide range of output pulse widths for different applications.
Q2: How many output points are available on the ADM51-2?
A2: The ADM51-2 module has 16 output points.
Q3: What is the output signal type for the ADM51-2 module?
A3: The module uses transistor contacts for output signals, which can handle inductive and resistive loads.
Q4: What is the maximum pulse width supported by the ADM51-2?
A4: The maximum pulse width that can be set is 7200 seconds.
Q5: How is the ADM51-2 module powered?
A5: The module operates at 24 V DC and consumes 130 mA of current.
Q6: What is the isolation capability of the ADM51-2?
A6: The ADM51-2 provides isolation between the output channels for safety and reliability.
Q7: Can the ADM51-2 module be used with existing terminal blocks?
A7: Yes, the ADT16 terminal block can be used with the ADM51-2 module, but the status display lamp will be disabled.
Q8: What are the dimensions and weight of the ADM51-2 module?
A8: The ADM51-2 has dimensions of 120 x 100 x 60 mm and weighs approximately 0.3 kg.
