Technical Specifications
| Item | Specification |
|---|---|
| Model | AAI835-S50 |
| Function | Analog I/O Module, 4-channel input / 4-channel output |
| I/O Signal Type | Input: 4 to 20 mA DC Output: 4 to 20 mA DC |
| Number of Channels | 4 input channels (isolated) 4 output channels (isolated) |
| Input Resistance (ON) | 290 Ω (at 20 mA) to 450 Ω (at 4 mA) |
| Input Resistance (OFF) | 500 kΩ or larger |
| Allowable Input Current | 25 mA |
| Allowable Load Resistance | 0 to 750 Ω |
| Circuit-open Detection | Less than 0.65 mA |
| Accuracy | Input: ±16 µA Output: ±48 µA |
| Data Update Period | 10 ms |
| Transmitter Power Supply | 15.0 V or higher (at 20 mA) 29.3 V or less (at 0 mA) |
| Temperature Drift | ±16 µA/10°C |
| HART Communication | Available (requires EB401 firmware rev. 2 or later when used with ER node unit) |
| External Connection | Pressure clamp terminal, MIL connector cable, dedicated cable (KS1) |
| Power Consumption | 360 mA (5 V DC), 450 mA (24 V DC) |
| Dimensions (W×D×H) | 107.5 × 32.8 × 130 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the AAI835-S50 module?
A1: It is a 4-channel analog input and 4-channel analog output module designed for 4 to 20 mA signal handling with isolated channels.
Q2: Is the AAI835-S50 suitable for intrinsically safe applications?
A2: A Zener barrier is not permitted. An isolation barrier must be used if applied in intrinsically safe zones.
Q3: Can the module be used in redundant configurations?
A3: Yes, it supports dual-redundant configurations to enhance system reliability.
Q4: Does the AAI835-S50 support HART communication?
A4: Yes, HART communication is supported, provided the ER bus node unit has EB401 firmware version 2 or later.
Q5: What is the load resistance range supported by the analog output channels?
A5: The output channels support a load resistance range of 0 to 750 Ω.
Q6: What is the data update rate of the module?
A6: The data update period for the AAI835-S50 is 10 milliseconds.
Q7: What type of connection interface does the AAI835-S50 use?
A7: It supports pressure clamp terminals, MIL connector cables, and KS1 dedicated cables.
Q8: What are the dimensions and weight of the AAI835-S50 module?
A8: The module measures 107.5 × 32.8 × 130 mm and weighs approximately 0.3 kg
Frequently Asked Questions (FAQ)
Q1: What is the main function of the AAI835-S50 module?
A1: It is a 4-channel analog input and 4-channel analog output module designed for 4 to 20 mA signal handling with isolated channels.
Q2: Is the AAI835-S50 suitable for intrinsically safe applications?
A2: A Zener barrier is not permitted. An isolation barrier must be used if applied in intrinsically safe zones.
Q3: Can the module be used in redundant configurations?
A3: Yes, it supports dual-redundant configurations to enhance system reliability.
Q4: Does the AAI835-S50 support HART communication?
A4: Yes, HART communication is supported, provided the ER bus node unit has EB401 firmware version 2 or later.
Q5: What is the load resistance range supported by the analog output channels?
A5: The output channels support a load resistance range of 0 to 750 Ω.
Q6: What is the data update rate of the module?
A6: The data update period for the AAI835-S50 is 10 milliseconds.
Q7: What type of connection interface does the AAI835-S50 use?
A7: It supports pressure clamp terminals, MIL connector cables, and KS1 dedicated cables.
Q8: What are the dimensions and weight of the AAI835-S50 module?
A8: The module measures 107.5 × 32.8 × 130 mm and weighs approximately 0.3 kg.
