Technical Specifications
The Yokogawa AAI835-H50 is a 4-channel input and 4-channel output analog I/O module designed for use in demanding industrial control systems. It features full channel isolation and supports HART communication.
| Item | Specification |
|---|---|
| Model | AAI835-H50 |
| Number of Channels | 4 inputs / 4 outputs (isolated channels) |
| I/O Signal | Input: 4 to 20 mA Output: 4 to 20 mA |
| HART Communication | Supported |
| Allowable Input Current | 25 mA |
| Allowable Load Resistance | 0 to 750 Ω |
| Circuit Open Detection | Less than 0.65 mA |
| Accuracy | Input: ±16 µA Output: ±48 µA |
| Data Update Period | 10 ms |
| Transmitter Power Supply | 15.0 V or higher (at 20 mA) 29.3 V or less (at 0 mA) |
| Input Resistance (Power ON) | 290 Ω (at 20 mA) to 450 Ω (at 4 mA) |
| Input Resistance (Power OFF) | 500 kΩ or larger |
| Temperature Drift | ±16 µA / 10 °C |
| Withstanding Voltage | 500 V AC (1 min) between I/O channels and system |
| Maximum Current Consumption | 360 mA (5 V DC) 450 mA (24 V DC) |
| External Connection | Pressure clamp terminal, MIL connector, KS1 dedicated cable |
| Dimensions (W × D × H) | 107.5 × 32.8 × 130 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of analog signal does the AAI835-H50 support?
A1: It supports 4 to 20 mA current signals for both input and output, making it suitable for industrial standard analog control applications.
Q2: Does the AAI835-H50 support HART communication?
A2: Yes, the AAI835-H50 includes HART protocol support, enabling two-way digital communication with field devices.
Q3: Is channel isolation provided in this module?
A3: Yes, each channel is isolated from the others and from the system, enhancing safety and noise immunity.
Q4: Can the AAI835-H50 detect open circuit conditions?
A4: Yes, it features circuit-open detection with a threshold of less than 0.65 mA to identify wiring issues.
Q5: What is the accuracy rating of this module?
A5: Input accuracy is ±16 µA, and output accuracy is ±48 µA under standard operating conditions.
Q6: What is the data update rate of the AAI835-H50?
A6: The module refreshes data every 10 milliseconds, providing fast and reliable updates for control systems.
Q7: Is the AAI835-H50 suitable for use in redundant configurations?
A7: Yes, it can be used in dual-redundant configurations for high availability and fail-safe operation.
Q8: What kind of external connections are compatible with the AAI835-H50?
A8: The module supports pressure clamp terminals, MIL connectors, and dedicated KS1 cables for flexible field wiring options.
