Yokogawa AAI143-H50/A4S00 Analog Input Module

Yokogawa AAI143-H50/A4S00 Analog Input Module

Manufacturer:Yokogawa

Product Number:AAI143-H50/A4S00

Product Type:Analog Input Module

Origin:Japan

Dimensions:107.5×32.8×130 mm

Weight:0.3 kg

Views:27

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/03/1-35.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/2-18.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/3-16.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/4-20.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Specifications

The Yokogawa AAI143-H50/A4S00 Analog Input Module specifications are detailed in the table below:

Parameter Specification
Model Number AAI143-H50/A4S00
Input Channels 16 (isolated)
Input Signal 4 to 20 mA DC
Allowable Input Current 24 mA
Withstanding Voltage 1500 V AC (1 minute)
Input Resistance (Power ON) 270 Ω (20 mA) to 350 Ω (4 mA)
Input Resistance (Power OFF) 500 kΩ or larger
Accuracy ±16 µA
Data Update Period 10 ms
Transmitter Power Supply 19.0 V or higher (at 20 mA), 25.5 V or less (at 0 mA)
Maximum Current Consumption 230 mA (5 V DC), 540 mA (24 V DC)
Communication HART communication available
External Connection Pressure clamp terminal, MIL connector cable, dedicated cable (KS1)
Dimensions 107.5 × 32.8 × 130 mm
Weight 0.3 kg

Product Introduction

The Yokogawa AAI143-H50/A4S00 Analog Input Module is designed for high-precision data acquisition and monitoring in industrial automation systems. It is an isolated module that provides 16 input channels, making it suitable for applications requiring reliable signal processing. It supports 4 to 20 mA DC input signals, making it an ideal choice for integrating with various industrial transmitters.

This module is commonly used in Field Control Stations (FCS), DCS (Distributed Control Systems), and SCADA (Supervisory Control and Data Acquisition) systems, where accurate analog signal acquisition is essential.

Its HART communication functionality allows for advanced diagnostics and communication with smart field devices, improving efficiency and reducing maintenance downtime.


Applications

The AAI143-H50/A4S00 Analog Input Module is widely used in various industries, including:

  1. Oil & Gas Industry – Monitoring pressure, temperature, and flow sensors in refining and pipeline systems.
  2. Power Plants – Acquisition of turbine control signals, steam pressure, and temperature.
  3. Chemical & Petrochemical Plants – Precise monitoring of chemical processes.
  4. Water Treatment Facilities – Collecting data from flow meters, level sensors, and pH analyzers.
  5. Manufacturing & Process Automation – Used in automated production lines for process optimization.
  6. Pharmaceutical Industry – Ensuring precision in temperature and humidity monitoring for drug manufacturing.

Product Advantages

  1. High Accuracy – With an accuracy of ±16 µA, the module ensures reliable data acquisition.
  2. Isolation Protection – Provides 1500 V AC isolation, enhancing safety and reducing interference.
  3. Fast Data Processing – A 10 ms data update period ensures real-time data acquisition.
  4. HART Communication Support – Enables remote diagnostics and enhanced control.
  5. Robust Design – Designed for industrial environments with durable construction.
  6. Low Power Consumption – Optimized for efficiency, consuming only 230 mA at 5 V DC and 540 mA at 24 V DC.
  7. Easy Integration – Compatible with various FCS (Field Control Stations), ensuring seamless integration.
  8. Compact & Lightweight – With dimensions of 107.5 × 32.8 × 130 mm and a weight of 0.3 kg, it saves space in control panels.
  9. Dual-Redundant Configuration – Enhances system reliability in critical applications.
  10. Flexible Wiring Options – Supports pressure clamp terminal, MIL connector cable, and dedicated KS1 cables.
