Triconex 9662-110 3000570-310 Digital Output Termination Panel

Triconex 9662-110 3000570-310 Digital Output Termination Panel

Manufacturer:Triconex

Product Number:9662-110 3000570-310

Product Type:Digital Output Termination Panel

Origin:USA

Dimensions:114.3 × 196.85 × 107.95 mm

Weight:0.5 kg

Views:20

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/03/9662-110.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/9662-110-2-1.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/9662-110-3.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/9662-110-4.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Description

The Triconex 9662-110 3000570-310 Digital Output Termination Panel is a high-performance, non-commoned termination panel designed for use in industrial automation and safety systems. It provides a robust interface for connecting digital output signals to field devices, ensuring reliable and safe operation. This termination panel is engineered for seamless integration with Triconex safety and control systems, making it an essential component in process industries such as oil and gas, power generation, chemical processing, and manufacturing.

The 9662-110 3000570-310 termination panel is built to withstand harsh industrial environments, featuring a compact DIN-rail-compatible enclosure with an advanced printed circuit board (PCB) for secure electrical connections. It supports 16 independent output points, ensuring flexibility and efficiency in connecting to various output devices such as actuators, solenoids, and alarms.

This panel is part of the Triconex Tricon v9–v10 Systems, which are renowned for their fault-tolerant architecture, high availability, and compliance with safety integrity level (SIL) requirements.


Product Specifications

Parameter Specification
Model Number 9662-110
Type Digital Output Termination Panel
Number of Outputs 16 Independent Outputs
Output Type Non-Commoned Digital Output
Rated Voltage 24 VDC
Mounting DIN-rail Compatible
Enclosure Type Rugged Industrial Enclosure
Connection Type Screw-Terminal Blocks for Secure Wiring
Operating Temperature -20°C to +70°C
Dimensions (W × H × D) 114.3 × 196.85 × 107.95 mm (4.5″ × 7.75″ × 4.25″)
Weight 0.5 kg (1.1 lbs)
Compatible Modules Triconex Digital Output Modules

Key Features

  • 16-Point Non-Commoned Output Design: Provides individual wiring for each output, ensuring electrical isolation.
  • Industrial-Grade Reliability: Designed for mission-critical safety and automation applications.
  • DIN-Rail Mountable: Easy installation and secure attachment in control cabinets.
  • Rugged Construction: Built for harsh environments with high durability and robust PCB design.
  • Secure Electrical Connections: Equipped with screw-terminal blocks for reliable field wiring.
  • Seamless Integration: Designed for Triconex Tricon v9–v10 Systems, ensuring compatibility and easy system expansion.

Advantages

1. High Safety and Reliability

  • Supports fail-safe digital outputs, ensuring operational security in critical applications.
  • Provides fault tolerance and redundancy to meet SIL 2 and SIL 3 requirements.

2. Easy Installation and Maintenance

  • Tool-free DIN-rail mounting allows quick installation and replacement.
  • Secure terminal block connections ensure easy wiring and troubleshooting.

3. Flexibility in Industrial Applications

  • Non-commoned design allows for independent control of each output.
  • Can be used with a wide range of field devices, including motors, alarms, solenoids, and relays.

4. Compliance with Industry Standards

  • Certified for industrial use in hazardous environments.
  • Meets IEC 61508 and other international functional safety standards.

Applications

The Triconex 9662-110 Digital Output Termination Panel is widely used in various industrial sectors, including:

1. Oil & Gas

  • Emergency shutdown systems (ESD)
  • Fire and gas detection systems (F&G)
  • Compressor and turbine control

2. Power Generation

  • Turbine and boiler control
  • Generator protection systems
  • Safety shutdown applications

3. Chemical & Petrochemical

  • Reactor and batch process automation
  • Safety instrumented systems (SIS)
  • Tank monitoring and control

4. Manufacturing & Industrial Automation

  • Conveyor belt control
  • Machine safety interlocks
  • Alarm and indication systems

Latest Reports on Triconex 9662-110

  1. “Enhancing Industrial Safety with Advanced Termination Panels: Triconex 9662-110 in High-Risk Environments” – Published in Process Safety Journal (2025).
  2. “A Comparative Study on Digital Output Termination Panels for SIL 3 Applications” – Featured in Industrial Automation Review (2024).
  3. “Triconex 9662-110: Improving Control System Reliability in Oil and Gas Facilities” – White paper by Schneider Electric (2025).
  4. “Optimizing Digital Output Performance with Triconex 9662-110 in Power Plants” – Energy Systems Review (2024).
  5. “Field Testing of Triconex 9662-110 in Harsh Industrial Environments” – Technical report by ISA (2023).

Recommended Related Models

The following six models are related to the 9662-110, either from the same series or compatible with Triconex systems:

Model Description Voltage Output Type
9661-110 Digital Output Panel, Non-Commoned 115 VAC 16 Points
9662-610 Digital Output Panel, Commoned 24 VDC 16 Points
9662-810 Digital Output Panel, Commoned 24 VDC 16 Points
9664-110 Digital Output Panel, Non-Commoned 120 VDC 16 Points
9667-110 Digital Output Panel, Non-Commoned 48 VDC 16 Points
9668-110 Relay Output Panel, Non-Commoned Various 16 Points

Popular Triconex Models

The following six Triconex models are among the most widely used in industrial applications:

Model Description Application
3008 Main Processor Module Safety & Control
3624 Digital Output Module Industrial Automation
4351B Communication Module Networking & Data Exchange
3704E Analog Input Module Process Control
3805E Analog Output Module Automation Systems
9853-610 Current Output Termination Panel Analog Signal Handling
FAQ

FAQ (Frequently Asked Questions)

Q1: What is the purpose of the Triconex 9662-110 Digital Output Termination Panel?

A1: The 9662-110 termination panel is designed to connect 16 independent digital outputs to field devices in Triconex Tricon v9–v10 safety and automation systems.

Q2: How is the Triconex 9662-110 different from commoned termination panels?

A2: Unlike commoned panels, which share a single return path for multiple outputs, the 9662-110 provides independent wiring for each output, ensuring better isolation and reliability.

Q3: What industries commonly use the Triconex 9662-110?

A3: It is widely used in oil & gas, power generation, chemical processing, and manufacturing industries.

Q4: Can the 9662-110 be used with Triconex safety systems?

A4: Yes, it is fully compatible with Triconex safety systems, providing secure, fail-safe digital output termination.

Q5: What are the mounting requirements for this termination panel?

A5: The 9662-110 is DIN-rail mountable, allowing for easy installation in industrial control cabinets.

Q6: How does the 9662-110 contribute to system safety?

A6: The non-commoned design and electrical isolation help prevent fault propagation, ensuring system safety and reliability.
