Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Triconex |
| Product No. | 3504E |
| Product Type | High Density Digital Input Module |
| Type | TMR |
| Voltage | 24 or 48 VDC |
| Points | 64, commoned, DC coupled |
| DC Range | 20-72 VDC |
| Maximum Voltage | 72 VDC |
| Typical Hysteresis | 4 VDC / 7 VDC |
| Stuck Test | ON and OFF |
| Color Code | Dark Red |
| Dimensions | 150 x 130 x 45 mm |
| Weight | 0.8 kg |
FAQ
FAQ
Q1: What is the voltage range for the Triconex 3504E module?
A1: The voltage range is 20-72 VDC, with 24 or 48 VDC options available.
Q2: How many input points does the 3504E module have?
A2: The module has 64 input points, which are commoned and DC coupled.
Q3: What is the typical hysteresis value for the Triconex 3504E module?
A3: The typical hysteresis is 4 VDC for the 24 VDC range and 7 VDC for the 48 VDC range.
Q4: What is the stuck test for the Triconex 3504E module?
A4: The stuck test for the module includes both ON and OFF tests.
Q5: What is the maximum voltage allowed for the 3504E module?
A5: The maximum voltage allowed for the 3504E module is 72 VDC.
Q6: What color code is used for the Triconex 3504E module?
A6: The color code for this module is Dark Red.
Q7: What is the size and weight of the 3504E module?
A7: The dimensions of the module are 150 x 130 x 45 mm, and its weight is 0.8 kg.
Q8: Is the Triconex 3504E module suitable for DC-coupled applications?
A8: Yes, the Triconex 3504E module is DC coupled, making it suitable for DC-coupled applications.
