Product Overview
The Schneider TSX3708056DR1 is a modular base controller from the TSX Micro PLC family, designed for mid-range industrial automation applications. It combines integrated discrete I/O capabilities with expansion flexibility, built-in communication ports, and advanced processing power, making it suitable for diverse control tasks in industrial environments.
The TSX3708056DR1 features two embedded I/O modules (each offering 16 digital inputs and 12 digital outputs), supports additional modules via a modular architecture, and allows DIN rail or panel mounting for flexible deployment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | TSX3708056DR1 |
| Manufacturer | Schneider Electric |
| Product Series | TSX Micro |
| Type | Modular Base Controller |
| Number of Integrated I/O | 2 × (16 Digital Inputs + 12 Digital Outputs) |
| Maximum I/O Capacity | 120 I/O |
| Power Supply | 24 VDC or 110/240 VAC (depending on version) |
| Communication Interfaces | RS485, Modbus, UNI-TELWAY, ASCII |
| Memory Expansion | PCMCIA Card Slot |
| Real-Time Clock | Integrated |
| Programming Language | Ladder Logic, Instruction List (via PL7) |
| Mounting | DIN Rail / Panel Mounting |
| Cooling | Optional Forced Ventilation |
| Dimensions (W x H x D) | 227.9 x 151 x 152 mm |
| Weight | 1.6 kg |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature | -25°C to 70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Protection Rating | IP20 |
Key Features
-
Dual Integrated I/O: Two embedded discrete I/O modules provide a base capacity of 56 I/O.
-
Modular Design: Accommodates additional I/O, analog, communication, and counting modules via available half/standard format slots.
-
Integrated Communication: Supports both Modbus and UNI-TELWAY protocols for networking flexibility.
-
Real-Time Clock: Embedded for time-based automation and event stamping.
-
Flexible Memory Options: Includes PCMCIA card slot for application memory and backup.
-
Advanced Counting: Supports 500Hz counting on initial digital inputs and up to 10kHz on higher-end variants.
Advantages
-
Scalability: Expandable architecture to fit various application sizes, reducing upfront investment.
-
Ease of Integration: Compatible with Schneider’s existing automation software and accessories.
-
Durability: Industrial-grade design suitable for harsh environments with extended temperature and humidity ranges.
-
Maintenance-Friendly: Modular approach allows easy replacement or upgrade of individual components.
-
Communication Ready: Native support for multiple fieldbus standards, reducing the need for extra gateways.
Typical Applications
-
Manufacturing Automation: Controls conveyor systems, robotic arms, and machine tools.
-
Building Management Systems: HVAC control, lighting, and access control systems.
-
Water and Wastewater: Pump control, tank level monitoring, and treatment plant automation.
-
Energy Systems: Generator control, solar tracking systems, and power distribution management.
-
Packaging Lines: Coordinated control of labeling, wrapping, and sorting processes.
Latest Industry Report Titles Featuring TSX3708056DR1
-
“Modular PLC Advancements in Mid-tier Automation: Schneider TSX3708056DR1 Leading the Change”
-
“Scalability and Efficiency in Industrial Control: A Field Review of Schneider’s TSX Micro Series”
-
“Integrating Legacy Equipment with Modern Control Systems: A TSX3708056DR1 Case Study”
-
“Comparative Reliability Analysis: Schneider TSX Micro PLCs vs. CompactLogix”
-
“Optimizing Process Control with Schneider’s TSX3708056DR1 Modular Controller”
-
“Top Modular PLCs of 2025 – Why TSX3708056DR1 Remains a Strong Contender”
Related Schneider TSX Models
| Model Number | Description | I/O Capacity | Supply Voltage | Dimensions (mm) | Weight |
|---|---|---|---|---|---|
| TSX3705056DR1 | Compact base, 1 I/O module | 56 | 24 VDC | 227.9 x 151 x 152 | 1.5 kg |
| TSX3708056DR1 | Modular base, 2 I/O modules | 120 | 24 VDC / 240 VAC | 227.9 x 151 x 152 | 1.6 kg |
| TSX3710056DR1 | Modular base, higher capacity | 192 | 24 VDC / 240 VAC | 248 x 160 x 160 | 1.8 kg |
| TSX3721056DR1 | Modular with extended memory | 256 | 24 VDC / 240 VAC | 250 x 170 x 170 | 2.0 kg |
| TSX3722056DR1 | High-speed counting & analog | 256 + analog | 24 VDC | 260 x 170 x 170 | 2.1 kg |
| TSX3708056AR1 | Same as TSX3708056DR1, 110/240VAC supply | 120 | 110/240 VAC | 227.9 x 151 x 152 | 1.6 kg |
Popular Schneider Automation Models
| Model Number | Product Type | Key Functionality | Dimensions (mm) | Weight |
|---|---|---|---|---|
| M241CE40 | Logic Controller | Ethernet, Modbus TCP, CANopen | 198 x 90 x 85 | 0.5 kg |
| BMXP342020 | Modicon X80 CPU | Advanced automation controller | 190 x 100 x 80 | 0.65 kg |
| TM241CE24T | M241 Series PLC | Compact Ethernet-based controller | 110 x 90 x 85 | 0.45 kg |
| BMXDDI3202K | Discrete Input Module | 32-channel digital input | 90 x 70 x 70 | 0.3 kg |
| TM5SAI2PH | Analog Input Module | 2-channel high-precision analog inputs | 90 x 70 x 50 | 0.2 kg |
| BMXNOE0110 | Ethernet Communication Module | Modicon M340 Ethernet TCP/IP communication | 120 x 70 x 60 | 0.4 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum I/O capacity of the TSX3708056DR1?
A1: The TSX3708056DR1 supports up to 120 I/O points with the addition of external modules.
Q2: What types of communication protocols are supported?
A2: It supports Modbus, UNI-TELWAY, and ASCII communication via the terminal port.
Q3: Is there built-in analog support in TSX3708056DR1?
A3: No, but analog modules can be added externally through the modular slot system.
Q4: Can the TSX3708056DR1 be used in high-temperature environments?
A4: Yes, it can operate from 0°C to 60°C. Forced ventilation is recommended for higher temperatures.
Q5: How is programming performed on this controller?
A5: It is programmed using Schneider’s PL7 software using ladder or instruction list languages.
Q6: What type of mounting is supported?
A6: It can be mounted on DIN rails or directly onto control panels.
Q7: What is the significance of the real-time clock?
A7: It allows time-based automation, scheduling, and timestamp logging of events.
Q8: Does this controller support memory expansion?
A8: Yes, a PCMCIA slot is available for memory card-based expansion or backup.
