Schneider BMXDAI0805 Discrete Input Module

Product Description:

The Schneider BMXDAI0805 is part of the Modicon X80 range, a versatile and robust family of modules designed for use with the Modicon M580 and M340 Programmable Automation Controllers (PAC). This discrete input module features 8 capacitive inputs and is ideal for medium to large process applications. It operates with an input voltage range of 200V AC to 240V AC and supports 2-wire/3-wire proximity sensors in compliance with IEC 60947-5-2 and IEC 61131-2 standards. The module offers excellent isolation between channels, ensuring reliable performance in demanding environments.

This input module is designed for high reliability and energy efficiency, with a low power dissipation of 4.73W. It is equipped with several safety and diagnostic features, including external fuses for protection and multiple status LEDs for system monitoring. Additionally, the BMXDAI0805 meets various international safety and electromagnetic compatibility standards, including UL, CSA, and CE certifications.

Product Parameters:

Parameter Value
Discrete Input Number 8
Input Type Capacitive
Input Voltage 200V AC to 240V AC
Input Current 10.4 mA
Power Dissipation 4.73W
Current Consumption (3.3V DC) 76 mA
Current Consumption (24V DC) 93.6 mA
Insulation Resistance > 10 MΩ at 500V DC
Input Impedance 21,000 Ω
Voltage Detection Threshold > 164V AC sensor OK, < 80V AC sensor fault
MTBF Reliability 1,700,000 hours
Activation Response Time (AC) 10 ms
Deactivation Response Time (AC) 20 ms
Ambient Temperature for Operation 32°F to 140°F (0°C to 60°C)
Ambient Temperature for Storage -40°F to 185°F (-40°C to 85°C)
Relative Humidity 5% to 95% (non-condensing)
Protection Type External fuse (0.5A fast blow) per channel group
Weight 0.12 kg
Dimensions 160 x 100 x 35 mm
IP Rating IP20
Certification EAC, RCM, UL, CSA, CE

Product Features:

  • High-Quality and Reliable: Built with the latest innovative technology to ensure durability and longevity.

  • Versatile Compatibility: Compatible with 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2 and IEC 61131-2 Type 2.

  • Diagnostic LEDs: Provides operational feedback with a green RUN LED, green channel diagnostic LEDs, and red error LEDs for module status.

  • Protection Features: Comes with an external fuse per group of channel (0.5A fast blow) to protect against overloads.

  • Compliance with Industry Standards: Meets multiple international standards such as UL, CSA, IEC 61131-2, and more.

  • Compact Design: Compact and lightweight, making it suitable for integration in various control systems without occupying significant space.

Advantages:

  • Reduced Maintenance Costs: With a common platform for Modicon M580 and M340 PACs, the BMXDAI0805 reduces the need for different spare parts and training.

  • Robust Protection: Its external fuse and isolation between channels ensure high reliability in demanding environments.

  • Ease of Integration: The module is easy to integrate with a variety of sensors and is suitable for different industrial applications.

Applications:

  • Industrial Process Control: Suitable for monitoring and controlling discrete inputs in industrial processes.

  • Automation Systems: Ideal for integration into automation systems requiring high-quality and reliable input modules.

  • Safety and Fault Detection: Used in systems where fault detection and prevention are critical, especially in large and medium-scale automation setups.

Latest Reports/News:

  • “New Innovations in Schneider Electric’s Modicon X80 Range Enhances Automation Efficiency”

  • “Schneider’s BMXDAI0805 Input Module Sets New Standards in Process Control”

Related Product Recommendations:

Product Model Type Input Voltage Current Consumption (24V DC) Power Dissipation Certifications
BMXDAI0804 Discrete Input Module 200V AC to 240V AC 93.6 mA 4.73W UL, CSA, CE
BMXDAI0806 Discrete Input Module 200V AC to 240V AC 93.6 mA 4.73W UL, CSA, CE
BMXDAI0803 Discrete Input Module 200V AC to 240V AC 93.6 mA 4.73W UL, CSA, CE
BMXPPS3500 Power Supply Module 24V DC 200 mA 1.5W UL, CSA, CE
BMXDIP0805 Digital Input Module 24V DC 50 mA 2.5W UL, CSA, CE
BMXFIP0812 Fiber Input Module 24V DC 60 mA 3W UL, CSA, CE

Popular Schneider Models:

Product Model Type Input Voltage Current Consumption (24V DC) Power Dissipation Certifications
BMXAMI0810 Analog Input Module 24V DC 50 mA 3.6W UL, CSA, CE
BMXPPS3500 Power Supply Module 24V DC 200 mA 1.5W UL, CSA, CE
BMXAMM0600 Analog High-Level Module 24V DC 40 mA 2W UL, CSA, CE
BMXAMI0600 Analog Input Module 24V DC 50 mA 3W UL, CSA, CE
BMXDOL0805 Digital Output Module 24V DC 100 mA 4W UL, CSA, CE
BMXDAI0801 Discrete Input Module 24V DC 50 mA 2W UL, CSA, CE
FAQ

FAQ (Frequently Asked Questions):

Q1: What is the voltage range of the BMXDAI0805 Discrete Input Module?
A1: The BMXDAI0805 operates with an input voltage range of 200V AC to 240V AC.

Q2: What is the current consumption of the module at 3.3V DC?
A2: The typical current consumption at 3.3V DC is 76mA.

Q3: How many discrete inputs does the BMXDAI0805 module have?
A3: The module has 8 discrete inputs.

Q4: What are the protection features of this module?
A4: The BMXDAI0805 has an external fuse for each channel group (0.5A fast blow protection) and channel isolation.

Q5: What sensors are compatible with this module?
A5: It is compatible with 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2 and IEC 61131-2 standards.

Q6: What is the response time of the module?
A6: The AC activation response time is 10ms, and the deactivation response time is 20ms.

Q7: What certifications does the module have?
A7: It is certified by EAC, RCM, UL, CSA, CE.

Q8: What is the operating temperature range of the module?
A8: The module operates within a temperature range of 32°F to 140°F (0°C to 60°C).
