Schneider BMXART0814 Analog Low Level  Input Module

Schneider BMXART0814 Analog Low Level Input Module

Manufacturer:Schneider

Product Number:BMXART0814

Product Type:Analog Low Level Input Module

Origin:France

Dimensions:98 x 33 x 104 mm

Weight:0.165 kg

Views:3

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/04/BMXART0814.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/BMXART0814-2.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/BMXART0814-4.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/BMXART0814-6-1.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Overview:

The Schneider BMXART0814 is part of the Modicon X80 series, designed to handle low-level analog signals with high precision and reliability. This input module is specifically tailored for systems requiring accurate analog input processing for low-level signals such as voltage and resistance, commonly used in industrial automation systems. The module provides seamless integration with other Modicon X80 I/O modules, making it an ideal choice for controlling processes that involve precise measurements and control.

Key Features and Benefits:

  • Isolated Channels: Each of the 8 analog input channels is isolated, ensuring reliable signal processing even in electrically noisy environments.

  • Wide Input Range: Capable of handling various signal types such as voltage, thermocouples, temperature probes, and resistance-based inputs, this module offers flexibility for diverse industrial applications.

  • High Resolution: With a 16-bit sigma-delta analog-to-digital conversion, it ensures high-resolution measurements, ideal for low-level analog signals.

  • Cold Junction Compensation: External compensation for thermocouples via Pt100 probes guarantees accurate temperature measurements in harsh conditions.

  • Digital Filtering: The first-order digital filter improves signal stability, especially in noisy industrial settings.

  • Error Detection: Equipped with diagnostic LEDs, including green for RUN and red for error states, this module makes troubleshooting easy.

Applications:

  • Temperature Monitoring: Used with thermocouples or temperature probes for industrial temperature measurement and control.

  • Process Control: Suitable for applications in automated manufacturing, power generation, and chemical processes, where precise analog signal monitoring is critical.

  • Environmental Monitoring: Can be integrated into systems that require continuous environmental monitoring, such as HVAC, pollution control, and energy efficiency systems.

Product Parameters:

Parameter Specification
Product Type Analog Input Module
Electrical Connection 40 ways 2 connectors
Input Level Low level
Number of Analog Inputs 8
Input Types Voltage, Resistance, Thermocouple, Temperature Probe
Analog-to-Digital Conversion Sigma Delta 16 bits
Resolution 15 bits + sign
Measurement Error +/- 0.7 °C Ni 1000 (25°C), +/- 2.7 °C Thermocouple U (25°C)
Overload Tolerance +/- 7.5 V
Common Mode Rejection 120 dB 50/60 Hz
Temperature Drift 25 ppm/°C (varies by type)
Ambient Temperature (Operation) 32…140 °F (0…60 °C)
Ambient Temperature (Storage) -40…185 °F (-40…85 °C)
Vibration Resistance 3 gn
Shock Resistance 30 gn
Weight 0.165 kg (0.364 lb)
Dimensions (L x W x H) 98 x 33 x 104 mm
Power Consumption 150 mA (3.3 V DC), 50 mA (24 V DC)
IP Rating IP20

Related Products (Same Series/Related Models):

Model Features
BMXART0815 Analog Low-Level Input Module, 16 channels
BMXAMI0800 Analog Input Module, High-Level Signals
BMXAMM0600 Analog High-Level I/O Module
BMXAMO0210 Analog Output Module
BMXART0414 Low-Level Input Module for a different series
BMXAMI0810 Analog Input Module, Voltage/Temperature Measurement

Popular Schneider Models:

Model Features
BMXAMI0810 Analog Input Module, designed for temperature and voltage
BMXART0910 Advanced analog input module for complex process control
BMXAMO0500 High-precision analog output module
BMXAMP1500 High-performance analog module with enhanced signal fidelity
BMXAMM0800 Multi-channel analog input module for industrial systems
BMXAMI1000 Multi-purpose analog input module
FAQ

Frequently Asked Questions (FAQ):

  1. Q: What types of signals can the BMXART0814 module handle?
    A: The module supports voltage, resistance, thermocouple, and temperature probe inputs, making it versatile for various industrial applications.

  2. Q: What is the resolution of the analog-to-digital conversion?
    A: The BMXART0814 uses a 16-bit sigma-delta analog-to-digital conversion with a resolution of 15 bits plus sign.

  3. Q: How does the BMXART0814 ensure accuracy in temperature measurements?
    A: The module offers cold junction compensation with an external Pt100 probe, ensuring accurate thermocouple temperature readings.

  4. Q: What is the operating temperature range of the BMXART0814?
    A: The module operates within a temperature range of 32…140 °F (0…60 °C).

  5. Q: What is the power consumption of the BMXART0814?
    A: It consumes 150 mA at 3.3 V DC and 50 mA at 24 V DC.

  6. Q: How does the module handle overload conditions?
    A: The BMXART0814 can tolerate input overloads of +/- 7.5 V on all its input types.

  7. Q: Does the BMXART0814 have any diagnostic features?
    A: Yes, it includes multiple LED indicators: a green RUN LED, a red error LED, and individual channel diagnostic LEDs.

  8. Q: Can the BMXART0814 be used in harsh environments?
    A: Yes, it is designed to withstand industrial environments, with shock resistance up to 30 gn and vibration resistance of 3 gn.
