Schneider 170ADM35010 Discrete I/O Module

The Schneider Electric 170ADM35010 Discrete I/O Module is designed for seamless integration into automation systems, offering high reliability and ease of use in industrial control applications. This module is particularly ideal for systems requiring fast switching and high input/output (I/O) performance with its advanced solid-state technology. It supports 16 discrete inputs and outputs, with two groups of 8 outputs and one group of 16 inputs. This module is well-suited for various industries where precise control of discrete signals is needed.

Key Features of the Schneider 170ADM35010:

  • Solid-State Technology: Utilizes solid-state switching for both inputs and outputs.

  • Input and Output Configuration:

    • 16 discrete inputs (24 V DC, positive logic).

    • 16 discrete outputs (solid-state, 24 V DC, positive logic).

  • Fast Response Time: Input and output transitions occur in less than 0.1 ms for outputs, ensuring quick system responses.

  • Compact Design: The module is designed with a compact footprint for easy installation in space-constrained environments.

  • High Power Rating: Capable of handling up to 8 A per module for outputs, and 5 A peak current for each output.

  • LED Signaling: Local signaling via 16 LEDs for monitoring channel status in real time.

Advantages:

  • Durability: Protective treatment and robust design ensure long-lasting performance even in harsh industrial environments.

  • High Current Handling: Can manage high current loads, up to 8 A per module, ensuring reliable performance for large control systems.

  • Easy Integration: With standard PLC connections, it ensures seamless integration into existing systems.

  • Cost-effective: This module provides excellent performance at an affordable price point, making it suitable for a range of industrial automation applications.

  • High Isolation: Offers 500 V AC isolation between channels and bus, ensuring operational safety.

Applications:

  • Factory Automation: Used in manufacturing lines for controlling machinery and processes with discrete inputs and outputs.

  • Building Automation: Controls various building systems, such as lighting, HVAC, and security systems.

  • Energy Management: Ideal for managing power distribution and switching for various industrial systems.

  • Process Control Systems: Excellent choice for controlling discrete equipment in chemical, oil, and gas industries.

Latest Reports and Articles:

  • “Schneider Electric’s I/O Modules and Their Role in Advanced Automation Systems”

  • “Maximizing Efficiency with Schneider 170ADM35010 in Critical Manufacturing Applications”

  • “The Future of Discrete I/O Modules in Industrial Control Systems”

Technical Specifications:

Parameter Value
Discrete Inputs (IEC 1131-2 Type) 16 inputs (24 V DC, Positive logic)
Discrete Outputs 16 outputs (24 V DC, Solid-state, Positive logic)
Output Current per Group 4 A per group, 8 A per module
Maximum Leakage Current 1 mA at 24 V DC (output circuit)
Input Voltage 3 to 30 V DC
Output Voltage <= 30 V DC
Voltage State 0 (Input) -3 to 5 V
Voltage State 1 (Input) 11 to 30 V
Input Resistance 4 kOhm
Current State 1 (Input) >= 2.5 mA
Current State 0 (Input) <= 1.2 mA
Response Time (Output) < 0.1 ms from state 0 to state 1, < 0.1 ms from state 1 to state 0
Response Time (Input) 2.2 ms from state 0 to state 1, 3.3 ms from state 1 to state 0
Isolation Between Channels and Bus 500 V AC
Power Dissipation 6 W max
Current Consumption 250 mA at 24 V DC
Dimensions 47.5 × 125 × 141.5 mm
Weight 0.2 kg
Environment Temperature Range (Operating) 0°C to 60°C
Environment Temperature Range (Storage) -40°C to 85°C
Humidity 95% without condensation
Altitude <= 5000 m

Dimensions and Weight:

  • Depth: 47.5 mm

  • Height: 141.5 mm

  • Width: 125 mm

  • Weight: 0.2 kg

Product Certifications:

  • UL/CSA Compliance

  • Electrostatic Discharge Resistance (IEC 801-2): 4 kV contact, 8 kV air

  • Electromagnetic Field Resistance (IEC 801-3): 10 V/m (80-1000 MHz)

Recommended Related Models:

Model Number Type Description I/O Configuration Power Dissipation Current Handling
170ADM35110 Discrete I/O Module Similar to 170ADM35010, supports 32 discrete I/O points 16 Inputs, 16 Outputs 6 W 8 A per module
170ADN35010 Analog Input Module Analog I/O for precision measurement applications 8 Analog Inputs 8 W 4 A per module
170AVD35010 Discrete I/O Module Compact I/O module for smaller systems 8 Inputs, 8 Outputs 5 W 4 A per group
170AMA35010 Multi-functional Module Multi-functional input/output module 16 Inputs, 16 Outputs 6 W 6 A per module
170ADC35010 Discrete I/O Module Reliable I/O for high-frequency systems 16 Inputs, 16 Outputs 7 W 8 A per module
170ACD35010 High-speed I/O Module High-speed I/O with advanced signal processing 16 Inputs, 16 Outputs 7 W 8 A per module

Popular Schneider Electric Models:

Model Number Type Description I/O Configuration Power Dissipation Current Handling
140CPU11303 PLC Controller High-performance PLC controller 16 Inputs, 16 Outputs 10 W 10 A per module
170ENT11000 Ethernet Communication Provides network communication for I/O modules N/A 5 W N/A
171CCC96000 Control Module Compact control solution for smaller applications 8 Inputs, 8 Outputs 4 W 3 A per module
170DTI9200 Digital Input Module High-density digital input module 32 Inputs 6 W 5 A per module
170ADM35100 Discrete I/O Module Versatile I/O module for industrial applications 16 Inputs, 16 Outputs 8 W 8 A per module
140DRA84000 Analog Output Module High-precision analog output for industrial use 8 Outputs 6 W 5 A per module
FAQ

Frequently Asked Questions (FAQs)

Q1: What is the response time for inputs and outputs in this module?

  • A1: The module has a response time of <0.1 ms from state 0 to state 1 and from state 1 to state 0 for outputs, and 2.2 ms (state 0 to state 1) and 3.3 ms (state 1 to state 0) for inputs.

Q2: What is the maximum current that the outputs can handle?

  • A2: The maximum current per group is 4A, and the module can handle up to 8A in total across all outputs.

Q3: What type of protection does the module have?

  • A3: The module offers overload protection on output circuits, with electrostatic discharge resistance up to 4 kV contact and 8 kV air, and protection against electromagnetic fields (10V/m).

Q4: What certifications does this module have?

  • A4: The module is certified by UL and CSA, meeting global industrial safety standards.

Q5: Can the module be used in outdoor environments?

  • A5: The module is designed to operate in ambient temperatures between 0°C and 60°C and can be stored at temperatures between -40°C and 85°C. It is suitable for indoor use or in environments protected from direct exposure.

Q6: How is the module powered?

  • A6: The module requires a 24V DC power supply to operate and consumes 250mA at 24V DC.

Q7: What is the isolation rating between channels and the bus?

  • A7: The module offers 500V AC isolation between channels and the bus, ensuring reliable and safe operation in industrial environments.

Q8: What is the size and weight of the module?

  • A8: The module has dimensions of 47.5 × 125 × 141.5 mm and weighs 0.2 kg, making it compact and easy to integrate into control panels.
