Schneider 140CPS12400 Power Supply Module

Schneider 140CPS12400 Power Supply Module

Manufacturer:Schneider

Product Number:140CPS12400

Product Type:Power Supply Module

Origin:France

Dimensions:103.9 × 40.3 × 250 mm

Weight:0.65 kg

Views:24

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/03/Schneider-140CPS12400-1-1.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/Schneider-140CPS12400-2.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/Schneider-140CPS12400-3.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/Schneider-140CPS12400-4.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Overview

The Schneider 140CPS12400 is a redundant power supply module designed for industrial applications. It ensures reliable power delivery in demanding environments, making it suitable for use in automation systems, control panels, and other critical infrastructure. This module is part of Schneider Electric’s extensive range of power supply solutions, known for their durability, efficiency, and compliance with international standards.


Key Parameters

Parameter Specification
Product Type Power Supply Module
Power Supply Type Redundant, Complementary
Input Voltage 115 V (93…138 V) AC, 47…63 Hz; 230 V (170…276 V) AC
Input Current 1100 mA (115 V); 600 mA (230 V)
Inrush Current 19 A (230 V); 38 A (115 V)
Rated Power 130 VA
Fuse Rating 2 A, slow-blow
Harmonic Distortion ≤ 10% of fundamental RMS value
Output Voltage 5.1 V DC
Output Current 8 A at 140 °F (60 °C) redundant
Overvoltage Protection Internal
Overload Protection Internal
Power Dissipation 6 + (1.5 x Iout) where Iout is in A
Local Signalling 1 LED (green) for power (PWR OK)
Certifications CE, cUL, FM Class 1 Division 2
ESD Resistance 4 kV contact (IEC 801-2); 8 kV on air (IEC 801-2)
EMF Resistance 9.1 V/m (10 V/m) 80…2000 MHz (IEC 801-3)
Operating Temperature 32…140 °F (0…60 °C)
Storage Temperature -40…185 °F (-40…85 °C)
Relative Humidity 95% without condensation
Operating Altitude ≤ 16404.2 ft (5000 m)
Dimensions 103.9 × 40.3 × 250 mm
Weight 0.65 kg

Product Features and Advantages

  1. Redundant Design: Ensures continuous operation even if one power supply fails, enhancing system reliability.
  2. Wide Input Voltage Range: Supports both 115 V and 230 V AC inputs, making it versatile for global applications.
  3. Robust Protection: Includes internal overvoltage and overload protection to safeguard connected equipment.
  4. High Efficiency: Optimized power dissipation ensures energy efficiency and reduces heat generation.
  5. Compliance with Standards: Meets UL 508, CSA C22.2 No 142, and FM Class 1 Division 2 standards, ensuring safety and reliability.
  6. Compact and Lightweight: With dimensions of 103.9 × 40.3 × 250 mm and a weight of 0.65 kg, it is easy to integrate into existing systems.
  7. Wide Operating Temperature Range: Functions reliably in temperatures from 0 to 60 °C, suitable for harsh environments.
  8. LED Indicators: Provides clear visual feedback on power status for easy monitoring.

Applications

The Schneider 140CPS12400 is ideal for:

  • Industrial automation systems
  • Control panels and PLCs
  • Process control systems
  • Critical infrastructure requiring redundant power supplies
  • HVAC systems
  • Telecommunications equipment

Latest News Headline

“Schneider Electric Enhances Industrial Power Solutions with the 140CPS12400 Redundant Power Supply Module”


Recommended Related Models

Model Number Input Voltage Output Voltage Output Current Power Rating Dimensions Weight
140CPS11100 115/230 V AC 5 V DC 8 A 130 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS11400 115/230 V AC 24 V DC 5 A 120 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS21100 115/230 V AC 5 V DC 10 A 150 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS21400 115/230 V AC 24 V DC 6 A 144 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS31100 115/230 V AC 5 V DC 12 A 180 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS31400 115/230 V AC 24 V DC 7.5 A 180 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS41100 115/230 V AC 5 V DC 15 A 200 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS41400 115/230 V AC 24 V DC 8 A 192 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS51100 115/230 V AC 5 V DC 20 A 250 VA 103.9 × 40.3 × 250 mm 0.65 kg
140CPS51400 115/230 V AC 24 V DC 10 A 240 VA 103.9 × 40.3 × 250 mm 0.65 kg

Top 10 Popular Schneider Models

Model Number Input Voltage Output Voltage Output Current Power Rating Dimensions Weight
ABL2REM24045 100-240 V AC 24 V DC 1.87 A 45 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24075 100-240 V AC 24 V DC 3.2 A 75 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24120 100-240 V AC 24 V DC 5 A 120 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24020 100-240 V AC 24 V DC 0.83 A 20 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24010 100-240 V AC 24 V DC 0.42 A 10 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24030 100-240 V AC 24 V DC 1.25 A 30 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24060 100-240 V AC 24 V DC 2.5 A 60 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24090 100-240 V AC 24 V DC 3.75 A 90 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24150 100-240 V AC 24 V DC 6.25 A 150 W 125 × 40 × 105 mm 0.5 kg
ABL2REM24200 100-240 V AC 24 V DC 8.33 A 200 W 125 × 40 × 105 mm 0.5 kg
FAQ

Frequently Asked Questions (FAQ)

Q1: What is the purpose of the redundant power supply design?
A1: The redundant design ensures uninterrupted power supply by allowing a backup power source to take over if the primary source fails.

Q2: Can the 140CPS12400 operate in extreme temperatures?
A2: Yes, it operates reliably in temperatures ranging from 0 to 60 °C.

Q3: Is this module suitable for use in hazardous environments?
A3: Yes, it is certified for FM Class 1 Division 2, making it suitable for hazardous locations.

Q4: What is the significance of the LED indicator?
A4: The green LED indicates the power status (PWR OK), providing visual confirmation of proper operation.

Q5: Can the 140CPS12400 be used at high altitudes?
A5: Yes, it is designed to operate at altitudes up to 5000 meters.

Q6: What is the harmonic distortion level of this module?
A6: The harmonic distortion is ≤ 10% of the fundamental RMS value.

Q7: Does the module include overvoltage protection?
A7: Yes, it features internal overvoltage protection.

Q8: What is the power dissipation formula for this module?
A8: The power dissipation is calculated as 6 + (1.5 x Iout), where Iout is the output current in amps.

Q9: Is the 140CPS12400 compliant with international standards?
A9: Yes, it complies with UL 508, CSA C22.2 No 142, and IEC 801 standards.

Q10: What is the weight and size of the module?
A10: It measures 103.9 × 40.3 × 250 mm and weighs 0.65 kg.
