Product Overview

The ICS Triplex T9300 I/O Backplane (paired with the T9851 Digital Output Termination Assembly) is an integral component of the AADvance® safety control system, offering a reliable and scalable solution for industrial automation. It serves as the central platform for connecting I/O modules and facilitates communication between the I/O modules and processor units, ensuring efficient and fault-tolerant system performance in critical applications.

Key Features

  • Modular Design: The T9300 I/O Backplane supports up to 3 I/O modules, providing flexibility for different system configurations.

  • Dual Bus Support: It features two I/O buses (I/O Bus 1 and I/O Bus 2) for efficient communication across multiple modules and base units.

  • Redundancy: The backplane supports dual or triple redundancy configurations, which is crucial for applications requiring high availability and fault tolerance.

  • Hot-Swapping Capability: Modules can be replaced without system downtime, ensuring continuous operation in mission-critical systems.

  • Diagnostic and Fault Indicators: It provides real-time diagnostics and status indicators to assist with system monitoring and fault detection.

Product Specifications

Parameter Description
Dimensions 233 x 126 x 18 mm
Weight 0.133 kg
Power Supply 18-32 Vdc
Maximum Current 400 mA per slot
Mounting DIN Rail
Environmental Range -30°C to +80°C
Expansion Capability Supports additional I/O base units via expansion cables
Field Wiring Compatible with a range of termination assemblies
Status Indicators LED indicators for system diagnostics

Product Advantages

  • Scalability: The modular design of the T9300 allows for easy expansion, making it ideal for growing automation systems.

  • Redundancy: Dual and triple redundancy options ensure high system reliability and operational uptime in safety-critical environments.

  • Real-Time Diagnostics: Built-in diagnostics and fault indicators allow for quick troubleshooting and maintenance.

  • Flexible Installation: Supports both standard and hot-swapping configurations, making installation and upgrades simple and efficient.

Applications

The T9300 I/O Backplane is commonly used in:

  • Safety Instrumented Systems (SIS) for critical industries like oil & gas, power generation, and chemical processing.

  • Redundant Control Systems in industries where downtime must be minimized.

  • Process Control Systems requiring robust communication between modules and processors.

Latest News Headlines

  • “ICS Triplex T9300: Revolutionizing Safety and Automation in High-Risk Environments”

  • “Enhancements to ICS Triplex T9300 I/O Backplane Ensure Seamless Integration and Scalability”

Related Products (from the AADvance System)

Model Description Key Features
T9300 I/O Base Unit Holds up to 3 I/O modules
T9310 Expansion Cable Assembly Expands I/O system with additional rows
T9401 Digital Input Module, 8-channel Isolated, 24 Vdc input
T9451 Digital Output Module, 8-channel Isolated, 24 Vdc output
T9481 Analog Output Module, 3-channel Isolated, 24 Vdc output
T9851 Digital Output Termination Assembly 8-channel, simplex, 24 Vdc output

Popular ICS Triplex Models

Model Description Key Features
T9100 Processor Base Unit Core unit for processor modules
T9300 I/O Base Unit Modular I/O base with expansion options
T9110 Processor Module Redundant processor support
T9401 Digital Input Module 8 channels, isolated
T9431 Analog Input Module 8 channels, isolated
T9451 Digital Output Module 8 channels, isolated
FAQ

FAQs (Frequently Asked Questions)

Q1: What is the power supply requirement for the T9300?

  • A1: The T9300 requires a power supply of 18-32 Vdc.

Q2: Can the T9300 support additional I/O modules beyond 3?

  • A2: Yes, additional I/O base units can be added using expansion cables to expand the system.

Q3: How is the T9300 mounted?

  • A3: The T9300 is mounted on a DIN rail, secured with clips for stability.

Q4: What is the weight of the T9300 I/O Backplane?

  • A4: The T9300 weighs 0.133 kg.

Q5: Does the T9300 support hot-swapping of modules?

  • A5: Yes, the T9300 supports hot-swapping of modules, allowing for maintenance without system downtime.

Q6: What is the environmental temperature range for the T9300?

  • A6: The T9300 can operate in temperatures ranging from -30°C to +80°C.

Q7: How does the T9300 handle diagnostics?

  • A7: The T9300 has built-in diagnostic indicators, including LED status lights to assist with fault detection and system monitoring.

Q8: Can the T9300 be used in hazardous environments?

  • A8: Yes, the T9300 is designed for use in hazardous environments, with certifications such as ATEX and IECEx for compliance with safety standards in industrial applications.
