Product Overview
The ICS Triplex T9300 I/O Backplane (often paired with the T9801 Digital Input Termination Assembly) is part of the AADvance® safety controller system. It serves as the physical interface between the controller and the I/O modules, allowing for high reliability, fault tolerance, and scalability in safety-critical applications.
This backplane is designed to support a variety of I/O configurations and provides both communication and power distribution across the system, ensuring smooth interaction between processor modules, I/O modules, and termination assemblies. It is typically used in industrial automation systems, including safety instrumented systems (SIS), process control, and redundant architectures.
Key Features
-
Scalability: Supports up to 3 I/O modules per base unit, with easy expansion using expansion cables for larger systems.
-
Redundancy: Supports dual or triple redundancy for critical systems to ensure high availability.
-
Compact Design: Optimized for space efficiency in industrial control environments, helping reduce the overall footprint.
-
Diagnostics: Offers built-in diagnostic and fault logging capabilities for efficient troubleshooting and system monitoring.
-
High Voltage Range: Operates with a wide input voltage range (18-32 Vdc), ensuring compatibility with various industrial power systems.
-
Secure Mounting: Features secure DIN rail mounting with retaining clips to ensure physical stability and safety.
Product Specifications
| Parameter | Description |
|---|---|
| Dimensions | 233 x 126 x 18 mm |
| Weight | 0.133 kg |
| Power Supply | 18-32 Vdc |
| Max Current Per Slot | 400 mA |
| Mounting Type | DIN Rail |
| Environmental Range | -30°C to +80°C |
| Connection Type | Direct plug/socket connection |
| Status Indicators | LED indicators for diagnostics |
| Expansion Capability | Expansion cables supported |
Product Advantages
-
High Availability: The T9300 ensures that critical I/O connections remain stable with its redundancy support, ideal for mission-critical applications.
-
Simple Installation: Features DIN rail mounting, making installation straightforward and reducing the time spent on setup.
-
Fault Detection: The system provides real-time diagnostic information, which helps operators quickly identify and address issues.
-
Modular System: Its modular design allows users to add I/O modules and expand the system as needed without requiring major hardware changes.
Applications
The T9300 I/O Backplane is primarily used in:
-
Safety Instrumented Systems (SIS) for process industries.
-
Critical Control Systems in sectors such as oil and gas, power generation, and chemical processing.
-
Automation Systems requiring high reliability, such as those found in industrial manufacturing and robotics.
Latest News Headlines
-
“ICS Triplex T9300: The Backbone of Safe and Reliable Automation Systems”
-
“New Expansion Features for ICS Triplex T9300 Backplane Enhance System Scalability”
Related Products (from the AADvance System)
| Model | Description | Key Features |
|---|---|---|
| T9300 | I/O Base Unit | Supports up to 3 I/O modules |
| T9310 | Expansion Cable Assembly | Adds extra rows of I/O base units |
| T9401 | Digital Input Module, 8-channel | Isolated inputs, 24 Vdc |
| T9451 | Digital Output Module, 8-channel | Isolated outputs, 24 Vdc |
| T9481 | Analog Output Module, 3-channel | Isolated outputs, 24 Vdc |
| T9402 | Digital Input Module, 16-channel | Isolated inputs, 24 Vdc |
Popular ICS Triplex Models
| Model | Description | Key Features |
|---|---|---|
| T9100 | Processor Base Unit | Core unit for processor modules |
| T9300 | I/O Base Unit | Flexible I/O expansion support |
| T9110 | Processor Module | Redundant processor support |
| T9401 | Digital Input Module | 8 channels, isolated |
| T9431 | Analog Input Module | 8 channels, isolated |
| T9451 | Digital Output Module | 8 channels, isolated |
FAQ
FAQs (Frequently Asked Questions)
Q1: What is the power supply requirement for the T9300?
-
A1: The T9300 requires a power supply of 18-32 Vdc.
Q2: Can the T9300 backplane support expansion?
-
A2: Yes, the T9300 supports expansion through the T9310 expansion cables.
Q3: How many I/O modules can the T9300 accommodate?
-
A3: The T9300 can accommodate up to 3 I/O modules per base unit.
Q4: What is the weight of the T9300 backplane?
-
A4: The T9300 weighs 0.133 kg.
Q5: Does the T9300 backplane support redundancy?
-
A5: Yes, it supports both dual and triple redundancy configurations for critical applications.
Q6: What is the operating temperature range for the T9300?
-
A6: The T9300 operates in temperatures ranging from -30°C to +80°C.
Q7: How is the T9300 mounted in an industrial environment?
-
A7: The T9300 is mounted using DIN rails and secured with retaining clips.
Q8: Can I connect the T9300 to other ICS Triplex units?
-
A8: Yes, the T9300 can connect with other ICS Triplex units, such as the T9100 processor unit, via expansion cables.
