Technical Specifications
| Parameter | Details |
|---|---|
| Type Numbers | FS-SAI-1620m, FC-SAI-1620m, FA-SAI-1620m |
| Approvals | CE, TUV, UL, CSA, FM |
| Space Requirements | 4 TE, 3 HE (4 HP, 3U) |
| Power Requirements | 5 V DC, 35 mA; 24 V DC, 35 mA |
| Number of Input Channels | 16 |
| Input Range | 0-4.1 V |
| Input Resistance | > 1 MΩ |
| Max Load Capacitance | 100 nF |
| A/D Converter | 12-bit |
| A/D Converter Inaccuracy | ± 1 LSB |
| Module Inaccuracy | < 0.25% |
| Max Input Signal | ± 36 V DC |
| Cross Talk | > 60 dB |
| External Voltage Readback | 0-4.1 V, Input Resistance: Typically 1 MΩ |
| Dimensions | 20 × 190 × 128 mm |
| Weight | 0.14 kg |
FAQ
FAQ
-
Q1: What are the input voltage ranges for the FS-SAI-1620M?
-
A1: The input voltage range for the FS-SAI-1620M is 0 to 4.1 V.
-
-
Q2: How many input channels does the FS-SAI-1620M have?
-
A2: The FS-SAI-1620M has 16 input channels.
-
-
Q3: What are the power requirements for the FS-SAI-1620M?
-
A3: The power requirements are 5 V DC at 35 mA and 24 V DC at 35 mA.
-
-
Q4: What is the maximum load capacitance supported by the FS-SAI-1620M?
-
A4: The maximum load capacitance supported is 100 nF.
-
-
Q5: What is the maximum input signal for the FS-SAI-1620M?
-
A5: The maximum input signal is ± 36 V DC.
-
-
Q6: Can the FS-SAI-1620M be used in hazardous environments?
-
A6: Yes, it is approved for use in non-hazardous areas and Division 2 locations in compliance with FM 3611.
-
-
Q7: What is the accuracy of the FS-SAI-1620M module?
-
A7: The module’s accuracy is less than 0.25%, and the A/D converter has an inaccuracy of ± 1 LSB.
-
-
Q8: What are the approval certifications for the FS-SAI-1620M?
-
A8: The FS-SAI-1620M is certified for CE, TUV, UL, CSA, and FM.
-
