Honeywell FC-TSRO-08UNI Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | FC-TSRO-08UNI |
| Safety Classification | Up to SIL3 (IEC 61508 compliant) |
| Approvals | CE, UL, CSA, TUV (pending) |
| Nominal Input Voltage | 24 VDC |
| Maximum Input Voltage | 36 VDC |
| Relay Pick-up Voltage | 19.2 VDC |
| Typical Input Current | 40 mA at 24 VDC |
| Number of Output Channels | 8 |
| Maximum Output Current | 2 A (fused) |
| Minimum Output Current | 1 mA at 5 V |
| Maximum Output Voltage | 250 VAC / 250 VDC |
| Maximum Switched Load | 500 VA / 150 W |
| Relay Contact Ratings | 250 VAC 2A; 24 VDC 2A; 48 VDC 1A; 110 VDC 0.5A |
| Maximum Switching Frequency | 20 Hz |
| Fuses | 2 AT (slow-acting), 5 × 20 mm |
| Relay Contact Material | Gold flash over silver alloy |
| Isolation Coil to Contact | 3750 VAC |
| Isolation Contact to Contact | 1200 VAC |
| Ambient Temperature Range | –5°C to +60°C (23°F to 140°F) |
| DIN Rail Compatibility | TS32 / TS35 × 7.5 |
| Termination – Signal Wires | Max wire: 2.5 mm² (AWG 14), strip: 7 mm, torque: 0.5 Nm |
| Termination – Power Wires | Max wire: 16 mm² (AWG 8), strip: 7 mm, torque: 1.2 Nm |
| Module Dimensions (L×W×H) | 274 × 109 × 71 mm |
| Module Weight | 0.85 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of outputs does the FC-TSRO-08UNI support?
A1: The module provides 8 relay-based safe output channels, each capable of switching AC or DC loads up to 250 VAC or 250 VDC at a maximum of 2 A.
Q2: Is the FC-TSRO-08UNI suitable for SIL3 safety applications?
A2: Yes, it is certified for use in safety-critical applications up to SIL3 according to IEC 61508.
Q3: What is the purpose of the conformal coating in the FC-type variant?
A3: The conformal coating provides additional protection against humidity, dust, and other environmental contaminants, ensuring higher reliability in harsh environments.
Q4: How are the relays protected in this module?
A4: Each channel includes a fused NO field contact rated at 2 AT (slow-acting) for overcurrent protection.
Q5: Can this module be mounted on standard DIN rails?
A5: Yes, it supports mounting on both TS32 and TS35 × 7.5 DIN rails using a universal snap-in mechanism.
Q6: What is the expected electrical life of the relays?
A6: The electrical life depends on the switched load but is typically in the range of hundreds of thousands of operations under rated conditions.
Q7: What type of terminal connections does the module support?
A7: The module features screw terminals for both signal (2.5 mm² max) and power (16 mm² max) wiring, with specified strip lengths and tightening torques.
Q8: Is external power required for operation of the FC-TSRO-08UNI module?
A8: Yes, a common external power supply is connected via screw terminals, shared across all channels.
