Honeywell CC-TDOD51 51307087-175 Digital Output Module

Honeywell CC-TDOD51 51307087-175 Digital Output Module

Manufacturer:Honeywell

Product Number:CC-TDOD51 51307087-175

Product Type:Digital Output Module

Origin:USA

Dimensions:9-inch

Weight:0.68 kg

Views:19

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/03/CC-TDOD51-51307087-175-2-1.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/CC-TDOD51-51307087-175-3.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/CC-TDOD51-51307087-175-4.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/CC-TDOD51-51307087-175.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The Honeywell CC-TDOD51 51307087-175 is a Digital Output (DO) module designed for industrial automation and process control applications. It belongs to the Experion Series-C I/O family and provides reliable 24VDC sink-type outputs for controlling field devices such as solenoids, relays, and interposing relays. This module is engineered for high reliability, redundancy support, and electronic protection features, ensuring safe and robust operation in mission-critical environments.

Product Specifications

Parameter Details
Model CC-TDOD51
Part Number 51307087-175
Type Digital Output Module (DO)
Output Channels 32
Output Type Sink (Open Drain)
Load Voltage 15-30 VDC
Maximum Load Current 0.1 A per channel
Galvanic Isolation 1000 VAC RMS for System-to-Field
On-State Voltage 0V (Load Current @ 0.1A max)
Off-State Voltage 24V (typical)
Off-State Leakage Current 100 µA (max)
Turn-On/Turn-Off Time 10 ms (max)
Redundancy Support Yes, with CC-TDOD61 IOTA
Module Size 9 inches (228 mm)
Weight 0.68 kg (1.5 lbs)

Product Features

  • 32-channel digital output module designed for industrial control systems.
  • Sink-type (open drain) 24VDC outputs for controlling a wide range of field devices.
  • Electronic overcurrent protection for enhanced system reliability.
  • Configurable fail-safe state (FAILOPT) to either hold the last value or shed to a safe value.
  • Supports redundancy when used with the CC-TDOD61 IOTA.
  • Galvanic isolation between system and field power for increased safety.
  • Fast response time (10ms turn-on/turn-off time) for real-time applications.
  • Bussed output design, allowing a shared ground return for all channels.
  • Industrial-grade durability, suitable for harsh environments.

Product Advantages

  1. High Reliability: Built for critical process control applications with robust failover mechanisms.
  2. Redundancy Support: Can be used in redundant configurations to ensure continuous operation.
  3. Electronic Protection: Short-circuit and overcurrent protection reduce maintenance requirements.
  4. Compact Size: 9-inch form factor with high-density 32-channel outputs reduces panel space.
  5. Fast Switching Speed: 10ms response time ensures rapid operation in real-time control environments.
  6. Seamless Integration: Compatible with Experion Series-C I/O architecture, allowing smooth system expansion.
  7. Energy Efficient: Low power consumption and fail-safe configurable output states optimize energy usage.

Product Applications

  • Industrial automation systems in power plants, refineries, and chemical processing industries.
  • SCADA systems for remote and centralized monitoring and control.
  • Building automation for HVAC, lighting control, and access security.
  • Manufacturing process control in pharmaceuticals, food & beverage, and automotive industries.
  • Oil & gas pipeline monitoring and safety interlock systems.
  • Water and wastewater treatment plants requiring robust digital output control.

Related Models in the Same Series

Model Description
CC-TDOD61 Digital Output Module (Redundant version)
CC-PDOD51 24VDC Digital Output, SINK type
CC-PDOB01 24VDC Digital Output, Source type
CC-TDOB01 Digital Output Bussed 24VDC
CC-TDOR01 Digital Output Relay IOTA
CC-PUIO01 Universal Input/Output Module

Popular Honeywell Models

Model Description
CC-PAIH01 Analog Input with HART
CC-PAOH01 Analog Output with HART
CC-PDIL01 Digital Input 24VDC
CC-PDIH01 High Voltage Digital Input (110V/220V)
CC-PUIO31 Universal Input/Output (High Density)
FC-TSDI-1624 Digital Input Module
FAQ

Frequently Asked Questions (FAQ)

Q1: What is the main function of the Honeywell CC-TDOD51 module?
A1: The CC-TDOD51 is a 32-channel digital output module that provides 24VDC sink-type outputs for controlling field devices such as solenoids, relays, and actuators.

Q2: Does the CC-TDOD51 support redundancy?
A2: Yes, the CC-TDOD51 supports redundant operation when paired with the CC-TDOD61 IOTA.

Q3: What is the output voltage and current rating of the CC-TDOD51?
A3: The module operates at 15-30 VDC with a maximum 0.1A per channel.

Q4: What protection features are included in the module?
A4: The module has electronic overcurrent protection, galvanic isolation, and fail-safe configurable outputs.

Q5: What is the typical application of the CC-TDOD51 module?
A5: It is used in industrial automation, SCADA systems, process control, safety interlock systems, and building automation.

Q6: What is the response time of this module?
A6: The module has a turn-on/turn-off time of 10ms, making it suitable for real-time applications.

Q7: Can the CC-TDOD51 be used in hazardous environments?
A7: Yes, it is designed to meet industrial-grade standards for operation in harsh and hazardous environments.

Q8: What is the size and weight of the module?
A8: The module has a 9-inch (228 mm) form factor and weighs 0.68 kg (1.5 lbs).
