Honeywell CC-TDIL01 51308386-175 Digital Input Module

Honeywell CC-TDIL01 51308386-175 Digital Input Module

Manufacturer:Honeywell

Product Number:CC-TDIL01 51308386-175

Product Type:Digital Input Module

Origin:USA

Dimensions:150 x 30 x 120 mm

Weight:0.45 kg

Views:19

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/03/CC-TDIL01-51308386-175-5-1.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/CC-TDIL01-51308386-175-6.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/CC-TDIL01-51308386-175-7.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/CC-TDIL01-51308386-175-8.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Overview
The Honeywell CC-TDIL01 51308386-175 is a 24V DC Digital Input Module designed for industrial automation and control systems. Part of the Experion PKS Series C I/O family, it provides reliable signal acquisition for discrete input devices such as switches, sensors, and relays. Its rugged design ensures compatibility with harsh industrial environments, making it ideal for process control, manufacturing, and energy management applications.


Key Parameters

Parameter Specification
Input Type 24V DC Digital Input
Input Channels 32 channels
Voltage Range 18–30V DC
Isolation Channel-to-channel and system isolation
Response Time ≤5 ms
Operating Temperature -40°C to +70°C
Dimensions (H x W x D) 150 mm x 30 mm x 120 mm
Weight 0.45 kg
Certifications CE, ATEX, IECEx, UL, CSA

Product Features

  • High Channel Density: Supports 32 discrete input channels in a compact form factor.
  • Wide Voltage Range: Operates reliably within 18–30V DC, accommodating fluctuating power conditions.
  • Robust Isolation: Provides channel-to-channel and system-level isolation to prevent signal interference.
  • Extended Temperature Range: Functions in extreme temperatures from -40°C to +70°C.
  • Diagnostic Capabilities: Includes open-wire detection and fault reporting for proactive maintenance.

Advantages

  • Reliability: Engineered for 24/7 operation in demanding industrial environments.
  • Easy Integration: Compatible with Honeywell’s Experion PKS and C300 controllers.
  • Safety Compliance: Meets ATEX and IECEx standards for hazardous area installations.
  • Low Maintenance: Modular design allows quick replacement without system downtime.

Applications

  • Process control systems in oil & gas, chemical, and power generation plants.
  • Factory automation for monitoring sensors, switches, and safety interlocks.
  • Building management systems for HVAC and security device integration.

Latest News Headlines

  1. Honeywell Enhances Series C I/O Modules with Advanced Diagnostics for Industry 4.0.
  2. CC-TDIL01 Adopted in Smart Grid Projects for Real-Time Monitoring.
  3. Honeywell’s Digital Input Modules Achieve IECEx Certification for Hazardous Zones.

Recommended Related/Series Models

Model Type Channels Voltage Range Dimensions (mm) Weight (kg)
CC-TAIX01 Analog Input Module 16 4–20 mA / 1–5V 150 x 30 x 120 0.40
CC-TAOX01 Analog Output Module 16 4–20 mA 150 x 30 x 120 0.42
CC-PDIL51 Digital Input 24V 32 18–30V DC 150 x 30 x 120 0.44
CC-TDOR01 Digital Output Relay 16 24V DC / 120V AC 150 x 30 x 120 0.50
CC-TUI031 Universal I/O Module 32 Configurable 150 x 30 x 120 0.48
CC-TSP411 Speed Protection Module 8 24V DC 150 x 30 x 120 0.46

Popular Honeywell Models

Model Type Key Parameters Dimensions (mm) Weight (kg)
C300 Controller Process Controller Redundant operation, 500 ms scan time 200 x 150 x 80 1.20
Experion HS Safety System SIL 3 certified, 1000 I/O capacity 300 x 200 x 100 2.50
CC-PAIH51 HART Analog Input 16 channels, 4–20 mA with HART protocol 150 x 30 x 120 0.43
CC-PAOH51 HART Analog Output 16 channels, 4–20 mA with HART protocol 150 x 30 x 120 0.45
CC-TSV211 Servo Valve Positioner 8 channels, LVDT/RVDT input 150 x 30 x 120 0.47
CC-TPIX11 Pulse Input Module 8 channels, 10 kHz frequency input 150 x 30 x 120 0.44
FAQ

FAQ

Q1: What is the purpose of the CC-TDIL01 Digital Input Module?
A1: The CC-TDIL01 is designed to acquire discrete input signals from devices such as switches, sensors, and relays in industrial automation and control systems. It provides reliable signal processing for monitoring and control applications.

Q2: What voltage range does the CC-TDIL01 support?
A2: The module supports a wide voltage range of 18–30V DC, making it suitable for various industrial environments with fluctuating power conditions.

Q3: How many input channels does the CC-TDIL01 have?
A3: The CC-TDIL01 features 32 discrete input channels, allowing for high-density signal acquisition in a compact form factor.

Q4: Is the CC-TDIL01 suitable for use in hazardous environments?
A4: Yes, the module is certified for use in hazardous areas, meeting ATEX and IECEx standards for Zone 2 and Division 2 locations.

Q5: What diagnostic features does the CC-TDIL01 offer?
A5: The module includes open-wire detection and fault reporting capabilities, enabling proactive maintenance and reducing downtime.

Q6: Can the CC-TDIL01 be used in redundant configurations?
A6: Yes, the module supports redundancy when paired with a secondary CC-TDIL01 module on a redundant IOTA, ensuring system reliability.

Q7: What is the operating temperature range of the CC-TDIL01?
A7: The module operates reliably in extreme temperatures ranging from -40°C to +70°C, making it suitable for harsh industrial environments.

Q8: How do I troubleshoot a faulty channel on the CC-TDIL01?
A8: Use the module’s diagnostic LEDs to identify the faulty channel. Check the field wiring for breaks or loose connections, and ensure the input signal is within the specified voltage range.
