Product Overview

The Honeywell CC-TAIX01 51308363-175 is a high-level analog input module designed for use in the Experion Series C I/O system. This module supports both high-level analog and HART inputs, making it versatile for various industrial applications. It is designed to provide reliable and accurate data acquisition for process control systems.

Product Parameters

Parameter Specification
Model Number CC-TAIX01
Input Type Voltage, current (2-wire or self-powered transmitters)
Input Channels 16 Channels (12 Single Ended / 4 Differential)
Common Mode Rejection Ratio 70 dB (dc to 60 Hz, 500 Ω source imbalance)
Common Mode Voltage -6 to +5 V peak (dc to 60 Hz)
A/D Converter Resolution 16 bits
Input Range 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (through 250 Ω)
Normal Mode Rejection Ratio 19 dB (at 60 Hz)
Normal Mode Filter Response Single-pole RC, -3 dB @ 6.5 Hz
Maximum Normal Mode Input ± 30 Volts (differential inputs, no damage)
Crosstalk -60 dB (dc to 60 Hz, channel-to-channel)
Input Impedance > 10 MΩ (voltage inputs)
Maximum Input Voltage ± 30 Volts (any input referenced to common, no damage)
Input Scan Rate 50 ms
Hardware Accuracy ± 0.075% of full-scale (23.5°± 2°C) ± 0.15% of full-scale (0 to 60°C)
Transmitter Field Power Conditioning Individually Protected Current Limiting Circuits for Class 1, Div 2 non-incendive interfacing. No fusing required
Dimensions 6″ (Non-Redundant), 12″ (Redundant)
Weight 0.5 kg (Non-Redundant), 0.8 kg (Redundant)

Product Features

  • High-Level Analog Input: Supports 4-20mA DC inputs for traditional and HART devices.
  • HART Communication: Enables status and configuration data exchange with HART-enabled devices.
  • High Accuracy: 16-bit A/D converter ensures precise data acquisition.
  • Robust Design: Conformally coated for additional environmental protection.
  • Flexible Configuration: Supports both single-ended and differential inputs.

Product Advantages

  • Versatility: Suitable for a wide range of industrial applications.
  • Reliability: Designed for high reliability in harsh environments.
  • Ease of Integration: Compatible with the Experion Series C I/O system.
  • Enhanced Diagnostics: Provides detailed diagnostic information for maintenance.

Product Applications

  • Process Control: Ideal for monitoring and controlling process variables in industries such as oil and gas, chemical, and power generation.
  • HART Device Integration: Facilitates integration with HART-enabled field devices for advanced diagnostics and configuration.
  • Data Acquisition: Suitable for high-accuracy data acquisition systems in industrial automation.
