Technical Specifications
| Parameter | Specification |
|---|---|
| Input Channels | 32 |
| Galvanic Isolation | 1500 VAC RMS or ±1500 VDC |
| Isolation Technique | Optical (in IOM) |
| DI Power Voltage Range | 18 to 30 VDC |
| ON Sense Voltage/Current | 13 VDC (min) or 3 mA (min) |
| OFF Sense Voltage/Current | 5 VDC (max) or 1.2 mA (max) |
| Input Impedance | 4.2 KΩ |
| Absolute Delay Across Input | 5 ms ± 20% |
| Field Resistance for ON Condition | 300 Ω max @ 15 VDC |
| Field Resistance for OFF Condition | 30 KΩ min @ 30 VDC |
| Input Channel Scanning | Normal = 20ms; Fast = 5ms |
| Digital Input Resolution (SOE) | 1ms |
| Dimensions | 110 x 130 x 60 mm |
| Weight | 0.45 kg |
FAQ
FAQs (Q&A Format)
Q1: What is the voltage range for the DI power supply of the Honeywell CC-GDIL11 module?
A1: The DI power voltage range for the Honeywell CC-GDIL11 module is 18 to 30 VDC.
Q2: What type of isolation does the Honeywell CC-GDIL11 module use?
A2: The module uses optical isolation in the IOM (Input Output Module).
Q3: How many input channels does the CC-GDIL11 have?
A3: The CC-GDIL11 module has 32 input channels.
Q4: What is the galvanic isolation rating for the CC-GDIL11?
A4: The galvanic isolation for the CC-GDIL11 is 1500 VAC RMS or ±1500 VDC.
Q5: What is the ON Sense Voltage/Current for the module?
A5: The ON Sense Voltage is 13 VDC (minimum) and the current is 3 mA (minimum).
Q6: What is the absolute delay across the input filter and isolation?
A6: The absolute delay is 5 ms ± 20%.
Q7: What is the field resistance required for the guaranteed ON condition?
A7: The field resistance for a guaranteed ON condition is a maximum of 300 Ω at 15 VDC.
Q8: What is the size and weight of the Honeywell CC-GDIL11 module?
A8: The module has dimensions of 110 x 130 x 60 mm and weighs 0.45 kg.
