Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Analog Input with HART – Single Ended |
| Model Number | 8C-PAIHA1 (Coated) |
| Input Channels | 16 Single-Ended |
| Input Type | Current inputs from 2-wire or self-powered transmitters |
| Input Range | 4–20 mA (via 250 Ω resistor) |
| A/D Converter Resolution | 16 bits |
| Voltage Rating | 24 VDC |
| Module Current Rating | 110 mA |
| Input Scan Rate | 50 ms |
| Normal Mode Rejection Ratio (60 Hz) | 19 dB |
| Normal Mode Filter Response | Single-pole RC, -3 dB @ 6.5 Hz |
| Crosstalk (channel-to-channel) | -60 dB |
| Max Input Voltage (no damage) | ±30 VDC |
| Hardware Accuracy | ±0.075% FS @ 23.5 ±2°C, ±0.15% FS @ 0–60°C |
| Galvanic Isolation | 1000 VAC RMS or ±1000 VDC |
| Isolation Technique | iCoupler |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 85 °C |
| Installation/Removal Under Power | Supported |
| Agency Certifications | Class I, Div 2, Groups A–D; T4 / Zone 2 AEx/Ex nA IIC T4 |
| Dimensions (W x H x D) | 220 mm × 120 mm × 60 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many channels does the 8C-PAIHA1 module support?
A1: It supports 16 single-ended analog input channels, all HART-capable.
Q2: What is the input signal range for this module?
A2: It accepts 4–20 mA signals, typically from 2-wire or self-powered field transmitters.
Q3: Can the module be replaced while powered on?
A3: Yes, the 8C-PAIHA1 supports hot-swapping; installation and removal under power are permitted.
Q4: Is HART communication fully supported on all channels?
A4: Yes, all 16 channels support HART protocol for device configuration and process variable reading.
Q5: What is the update or scan rate for input signals?
A5: Each channel is scanned every 50 milliseconds.
Q6: How accurate is the module at different operating temperatures?
A6: Accuracy is ±0.075% of full scale at room temperature (23.5 ± 2°C) and ±0.15% from 0 to 60°C.
Q7: Does the module provide electrical isolation?
A7: Yes, the module provides 1000 VAC RMS or ±1000 VDC galvanic isolation using iCoupler technology.
Q8: What kind of certification does the module carry for hazardous environments?
A8: It is certified for Class I, Division 2, Groups A, B, C, D, and Zone 2 hazardous areas with Ex nA IIC T4 rating.
