Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | 10303/1/1 |
| Product Type | Power Supply Module |
| Input Voltage | 90–132 VAC / 180–264 VAC (auto-select) |
| Input Frequency | 47–63 Hz |
| Output Voltage | 5 VDC, 24 VDC |
| Output Power | Up to 75 W |
| Output Current | 5 V @ 6 A, 24 V @ 2 A |
| Efficiency | >80% |
| Overvoltage Protection | Yes |
| Overcurrent Protection | Yes |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Cooling Method | Natural convection |
| Mounting Type | DIN Rail or Panel Mount |
| Certifications | CE, UL, CSA |
| Dimensions (W x H x D) | 25 x 207 x 203 mm |
| Weight | 0.45 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What input voltage ranges does the Honeywell 10303/1/1 support?
A1: The module supports a wide input range of 90–132 VAC and 180–264 VAC, with automatic switching between ranges.
Q2: What are the output specifications for this power supply module?
A2: It provides 5 VDC at 6 A and 24 VDC at 2 A output levels, suitable for various industrial applications.
Q3: Does this power module include protection features?
A3: Yes, the unit comes with both overvoltage and overcurrent protection to ensure operational safety and reliability.
Q4: What is the cooling mechanism used in the 10303/1/1 module?
A4: The power supply uses natural convection for cooling, which eliminates the need for fans and reduces noise and maintenance.
Q5: Can the module be mounted on a DIN rail?
A5: Yes, it supports both DIN rail and panel mounting for flexible installation in control cabinets.
Q6: Is the Honeywell 10303/1/1 certified for industrial use?
A6: The module holds CE, UL, and CSA certifications, ensuring compliance with industry standards and safety regulations.
Q7: What is the efficiency level of this power supply?
A7: The module operates at an efficiency greater than 80%, which supports energy savings in continuous operation.
Q8: What are the dimensions and weight of the power module?
A8: The dimensions are 25 mm (W) x 207 mm (H) x 203 mm (D), and the unit weighs approximately 0.45 kg.
