Product Introduction:
The Honeywell 10201/2/1 Fail-safe Digital Output Module is a high-quality, robust output module designed for critical industrial applications requiring fail-safe performance. This module includes eight 24 Vdc output channels, each capable of driving loads up to 13 W. The module is designed to be used in fail-safe applications, ensuring the reliability of operations, especially in applications where safety and uptime are critical.
This module supports both resistive and inductive loads, such as lamps and solenoids. It features integrated suppression diodes for inductive loads, ensuring protection against voltage spikes caused by switching inductive loads. The module has been fully tested for fail-safe performance, including the ability to de-energize the load, de-energize the group via secondary means, and detect any cross-talk between output channels.
It is CE, TüV, and UL approved, ensuring compliance with international safety and quality standards.
Product Applications:
- Industrial Automation: Used in industrial systems to drive various types of loads, ensuring safe operation in critical processes.
- Process Control: Ideal for controlling valves, actuators, and solenoids in process control systems.
- Lighting Systems: Suitable for controlling lamps in safety systems or for general industrial lighting control.
- Fail-safe Operations: Ensures safety and performance in systems requiring fail-safe behavior, especially in hazardous environments.
Product Advantages:
- Fail-safe Performance: Fully tested outputs ensure reliable operation in critical safety applications.
- Versatile Load Handling: Suitable for both resistive and inductive loads, enhancing flexibility in various industrial setups.
- Compact and Efficient Design: The module is space-efficient with a small form factor and low power consumption, making it ideal for systems with limited space.
- Integrated Protection: Built-in suppression diodes on each output channel ensure safe operation with inductive loads, protecting the system from voltage spikes.
- Compliance with Standards: The module is CE, TüV, and UL certified, ensuring that it meets high safety and performance standards.
Latest Product Reports:
- “Enhancing Industrial Control Safety with Honeywell’s 10201/2/1 Fail-safe Digital Output Module”
- “Honeywell’s Fail-safe Digital Output Module: A Comprehensive Review for Industrial Applications”
- “The Role of Honeywell 10201/2/1 in Critical Automation Systems”
- “Improving System Reliability with Honeywell’s Fail-safe Output Modules”
- “Safety First: Honeywell 10201/2/1 Meets Global Safety Standards”
Product Parameters
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Product Number | 10201/2/1 |
| Product Type | Fail-safe Digital Output Module |
| Output Channels | 8 channels |
| Output Voltage | 24 Vdc |
| Maximum Output Current | 550 mA (per channel) |
| Maximum Lamp Load | 120 mA (2.9 W) |
| Maximum Load Capacitance | 1 μF |
| Voltage Drop | < 2.0 Vdc at 500 mA |
| Off Current | < 0.1 mA |
| WDG Input Current | 8 mA |
| Power Requirements | 5 Vdc 25 mA, 24 Vdc internal 25 mA, 24 Vdc external 70 mA |
| Dimensions | 30 x 200 x 150 mm |
| Weight | 0.15 kg |
| Approvals | CE, TüV, UL |
| Software Version | 3.00 |
| Space Requirements | 4 TE, 3 HE (4 HP, 3U) |
| Key Coding | See Key Coding Data Sheet |
| Module Code | Holes A9, C9 |
| Rack Code | Large pins A9, C9 |
Recommended Related Models (Same Series/Family)
| Model Number | Description | Output Channels | Voltage | Max Current | Max Load | Approvals | Software Version | Dimensions | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 10202/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, UL | 3.00 | 30 x 200 x 150 mm | 0.15 kg |
| 10203/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV, UL | 3.01 | 30 x 200 x 150 mm | 0.15 kg |
| 10204/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV, UL | 3.02 | 30 x 200 x 150 mm | 0.15 kg |
| 10205/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV | 3.03 | 30 x 200 x 150 mm | 0.15 kg |
| 10206/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV, UL | 3.04 | 30 x 200 x 150 mm | 0.15 kg |
| 10207/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, UL | 3.05 | 30 x 200 x 150 mm | 0.15 kg |
| 10208/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV | 3.06 | 30 x 200 x 150 mm | 0.15 kg |
| 10209/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV | 3.07 | 30 x 200 x 150 mm | 0.15 kg |
| 10210/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV | 3.08 | 30 x 200 x 150 mm | 0.15 kg |
| 10211/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV, UL | 3.09 | 30 x 200 x 150 mm | 0.15 kg |
Recommended Popular Honeywell Models
| Model Number | Description | Output Channels | Voltage | Max Current | Max Load | Approvals | Software Version | Dimensions | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 10101/1/1 | Fail-safe Digital Input Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV, UL | 3.10 | 30 x 200 x 150 mm | 0.15 kg |
| 10105/2/1 | Fail-safe High-density Analog Input Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV, UL | 3.00 | 30 x 200 x 150 mm | 0.15 kg |
| 10102/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV | 3.01 | 30 x 200 x 150 mm | 0.15 kg |
| 10201/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV, UL | 3.00 | 30 x 200 x 150 mm | 0.15 kg |
| 10401/1/1 | Fail-safe Analog Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV, UL | 3.00 | 30 x 200 x 150 mm | 0.15 kg |
| 10202/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV | 3.00 | 30 x 200 x 150 mm | 0.15 kg |
| 10103/1/1 | High-density Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, UL | 3.02 | 30 x 200 x 150 mm | 0.15 kg |
| 10501/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV | 3.03 | 30 x 200 x 150 mm | 0.15 kg |
| 10104/1/1 | Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, UL | 3.04 | 30 x 200 x 150 mm | 0.15 kg |
| 10203/2/1 | Fail-safe Digital Output Module | 8 | 24 Vdc | 550 mA | 13 W | CE, TüV | 3.05 | 30 x 200 x 150 mm | 0.15 kg |
FAQ
Product FAQs (Presented in QA Format)
Q1: What is the maximum current for each output channel on the 10201/2/1 module?
A1: The maximum current for each output channel is 550 mA.
Q2: Can this module handle inductive loads like solenoids?
A2: Yes, the module can handle inductive loads like solenoids, and it includes suppression diodes on each output to protect against voltage spikes.
Q3: What is the maximum lamp load the module can support?
A3: The maximum lamp load the module can support is 120 mA (2.9 W).
Q4: Is this module tested for fail-safe applications?
A4: Yes, the module is fully tested for fail-safe applications, including the ability to de-energize and handle cross-talk between outputs.
Q5: What is the voltage drop at 500 mA for this module?
A5: The voltage drop at 500 mA is less than 2.0 Vdc.
Q6: What certifications does the Honeywell 10201/2/1 module have?
A6: The module is certified with CE, TüV, and UL approvals.
Q7: What are the power requirements for this module?
A7: The power requirements are 5 Vdc 25 mA, 24 Vdc internal 25 mA, and 24 Vdc external 70 mA (without output load).
Q8: What is the space requirement for mounting this module?
A8: The module requires 4 TE, 3 HE, or 4 HP, 3U of space.
Q9: How is this module protected from inductive load spikes?
A9: Each output channel has an integrated suppression diode to protect the module from voltage spikes caused by inductive loads.
Q10: What are the dimensions and weight of this module?
A10: The module’s dimensions are 30 x 200 x 150 mm, and it weighs 0.15 kg.
