Product Overview
The HIMA F7130 Power Supply Module is an essential component in the PES H41q system. Designed as a DC/DC converter, it transforms a 24 VDC input into a 5 VDC output, providing power to various modules and interfaces in the HIMA system. This module ensures that the system operates smoothly, with overvoltage protection and current limitation features. It also comes with short-circuit protection to safeguard both the power supply module and connected devices.
This module is an integral part of the system, offering electrical isolation between the input and output voltage, thus ensuring stable and reliable operation. It is optimized for use in safety-related applications and is tailored for industrial control systems.
Key Product Features
-
Input Voltage: 24 VDC with a tolerance of -15% to +20%
-
Output Voltage: 5 VDC (± 0.25 V)
-
Output Current:
-
Central Device/IO Modules: 5 VDC, up to 10 A
-
HIBUS Interface: 5 VDC, up to 1 A
-
-
Efficiency Rate: ≥ 70%
-
Overvoltage Protection: Yes
-
Current Limitation: Yes
-
Short-Circuit Protection: Yes
-
Electrical Isolation: Between input and output
-
Space Requirement: 4 SU
-
Weight: 0.45 kg
Product Advantages
-
Reliable Power Supply: The F7130 ensures a stable 5 VDC output, even when the input voltage fluctuates within the specified tolerance range.
-
Safety Features: Equipped with overvoltage protection, current limitation, and short-circuit protection, the F7130 offers enhanced safety for the entire system.
-
Easy Monitoring: LEDs on the front panel indicate the status of the input and output voltage, making it easy to monitor the operation of the module.
-
Versatile Compatibility: Designed to work with central device/IO modules and HIBUS interfaces, it ensures compatibility with various system components.
-
Compact Design: The 4 SU space requirement ensures that the module is space-efficient, ideal for systems with limited space.
Applications
The F7130 Power Supply Module is primarily used in industrial control systems where reliable and continuous power is crucial. Key applications include:
-
Safety-Related Systems: It provides reliable power for monitoring and control tasks in safety-critical systems.
-
Central Device/IO Modules: Used to power central control units and input/output modules in automation systems.
-
Communication Systems: The HIBUS interface power supply ensures stable communication in distributed control systems.
Product Parameter Table
| Parameter | Specification |
|---|---|
| Input Voltage | 24 VDC, -15% to +20% |
| Output Voltage | 5 VDC ± 0.25 V |
| Output Current | 10 A for Central Device/IO Modules |
| 1 A for HIBUS Interface | |
| Efficiency Rate | ≥ 70% |
| Overvoltage Protection | Yes |
| Current Limitation | Yes |
| Short-Circuit Protection | Yes |
| Electrical Isolation | Yes |
| Space Requirement | 4 SU |
| Weight | 0.45 kg |
Recommended Models (Same Series/Related)
| Model | Description | Key Features |
|---|---|---|
| F7105A | Safety-Related Application Module | Similar input/output capabilities |
| F7140 | Power Supply for Central Devices | Higher output power for larger systems |
| F7120 | Distributed Control System Module | Integrated with advanced communication |
| F7115 | Compact Safety Module | Optimized for compact system designs |
| F7100 | Central Control Power Supply | Increased efficiency rate |
| F7150 | Advanced Power Supply for Complex Systems | Enhanced current protection features |
Popular HIMA Models
| Model | Description | Key Features |
|---|---|---|
| F8601 | Advanced Safety Module | High redundancy, fault tolerance |
| F8600 | Modular Safety Controller | Integrated diagnostics |
| F8205 | Digital Input Module | Optimized for high-speed input tasks |
| F8230 | Communication Interface Module | Supports multiple network protocols |
| F8300 | Safety Monitoring Module | Comprehensive safety monitoring |
| F8500 | Fieldbus Communication Module | Efficient for distributed systems |
FAQ
Frequently Asked Questions (FAQ)
-
Q: What is the input voltage range for the F7130?
A: The input voltage range for the F7130 is 24 VDC, with a tolerance of -15% to +20%. -
Q: What is the output voltage provided by the F7130?
A: The F7130 provides a 5 VDC output with a tolerance of ± 0.25 V. -
Q: How much current can the F7130 provide to the central device/IO modules?
A: The F7130 can provide up to 10 A to the central device/IO modules. -
Q: Does the F7130 offer short-circuit protection?
A: Yes, the F7130 is equipped with short-circuit protection. -
Q: What is the efficiency rate of the F7130?
A: The F7130 has an efficiency rate of ≥ 70%. -
Q: How is the status of the F7130 monitored?
A: The status of the F7130 is monitored through LEDs on the front panel, which indicate the input and output voltage status. -
Q: Is the F7130 module compatible with the HIBUS interface?
A: Yes, the F7130 provides power to the HIBUS interface, with an output of 5 VDC and up to 1 A. -
Q: What is the space requirement for installing the F7130?
A: The space requirement for the F7130 is 4 SU, making it compact for integration into systems with limited space.
