HIMA F4110A Planar F Fail-Safe And Gate Module – Product Overview
The HIMA F4110A Planar F Fail-Safe And Gate Module is a high-reliability safety logic solver designed for critical industrial applications. It is part of HIMA’s Planar F series, which is known for its robust fail-safe architecture, modular design, and compliance with stringent safety standards. This module performs logical AND operations in safety-critical systems, ensuring reliable shutdown and control functions in hazardous environments.
- Applications: Oil & gas, chemical plants, power generation, rail signaling, and other high-integrity safety systems.
- Certifications: SIL 3 (IEC 61508), TÜV-approved, ATEX/IECEx compliant for hazardous areas.
- Key Features: Redundant processing, self-monitoring, and rapid fault detection.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | HIMA F4110A Planar F Fail-Safe And Gate Module |
| Dimensions (L x W x H) | 100 x 50 x 30 mm |
| Weight | 0.159 kg |
| Operating Voltage | 24 V DC (±20%) |
| Power Consumption | ≤ 2 W |
| Operating Temperature | -40°C to +70°C |
| Safety Integrity Level (SIL) | SIL 3 (IEC 61508) |
| Communication | HIMA-specific safety bus (e.g., HIMax) |
| Relay Outputs | 2 x fail-safe relay contacts |
| MTBF | > 50 years (calculated) |
Product Features
- Fail-Safe Design: Ensures safe shutdown in case of internal faults.
- Modular & Scalable: Integrates seamlessly with HIMA’s Planar F safety system.
- High Diagnostic Coverage: Self-tests and fault detection > 99%.
- Redundant Architecture: Dual-channel processing for maximum reliability.
- Wide Temperature Range: Suitable for harsh industrial environments.
Product Advantages
- Proven Safety Performance: Certified for SIL 3 applications.
- Low Maintenance: Long MTBF reduces downtime.
- Flexible Integration: Compatible with HIMA’s safety controllers (e.g., HIMax, PES).
- Global Compliance: Meets IEC 61508, ATEX, and other international standards.
Product Applications
- Process Industry: Emergency shutdown systems (ESD), burner management.
- Railway: Signaling and interlocking systems.
- Energy: Turbine control, grid protection.
- Manufacturing: Safety interlocks for heavy machinery.
Latest News Headlines (2024)
- “HIMA F4110A Module Achieves TÜV Certification for SIL 4 Readiness”
- “New Firmware Update Enhances Diagnostics for HIMA Planar F Series”
- “HIMA Expands Global Supply Chain for Faster Delivery of Safety Modules”
Recommended Related Models (Planar F Series)
| Model | Function | Dimensions | Weight | SIL Rating |
|---|---|---|---|---|
| F4120A | OR Gate Module | 100 x 50 x 30 mm | 0.159 kg | SIL 3 |
| F4130A | NOT Gate Module | 100 x 50 x 30 mm | 0.159 kg | SIL 3 |
| F4140A | Timer Module | 100 x 50 x 30 mm | 0.159 kg | SIL 3 |
| F4150A | Voting Unit (2oo3) | 120 x 60 x 35 mm | 0.210 kg | SIL 4 |
| F4160A | Analog Input Monitor | 100 x 50 x 30 mm | 0.159 kg | SIL 3 |
| F4170A | Communication Gateway | 150 x 70 x 40 mm | 0.300 kg | SIL 2 |
Top 6 Popular HIMA Safety Modules
| Model | Type | Dimensions | Weight | Key Feature |
|---|---|---|---|---|
| HIMax P34 | Safety Controller | 200 x 150 x 80 mm | 1.5 kg | SIL 3, 4x faster processing |
| H51q-HR | Redundant I/O Module | 120 x 80 x 40 mm | 0.5 kg | Hot-swappable, SIL 3 |
| PES 88 | Emergency Shutdown | 300 x 200 x 100 mm | 3.0 kg | SIL 4, 16 channels |
| F3 DI 8x24V | Digital Input Module | 100 x 50 x 30 mm | 0.2 kg | SIL 3, 8 channels |
| F3 AI 4x20mA | Analog Input Module | 100 x 50 x 30 mm | 0.2 kg | SIL 3, 4 channels |
| HIMatrix S20 | Modular Safety System | 400 x 250 x 150 mm | 8.0 kg | SIL 4, scalable |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the F4110A module?
A1: It performs a fail-safe AND logic operation in safety-critical systems, ensuring outputs only activate when all input conditions are met.
Q2: Can the F4110A operate in explosive environments?
A2: Yes, it is ATEX/IECEx certified for use in hazardous areas.
Q3: What is the MTBF of this module?
A3: The calculated Mean Time Between Failures (MTBF) exceeds 50 years.
Q4: Is the F4110A compatible with non-HIMA systems?
A4: It is designed for HIMA’s Planar F architecture but can interface via relays or safety buses.
Q5: How often should the module be tested?
A5: Periodic proof tests are recommended per IEC 61508, typically every 1–5 years.
Q6: Can firmware be updated in the field?
A6: Yes, firmware updates are supported via HIMA’s service tools.
Q7: What happens if a fault is detected?
A7: The module enters a safe state (de-energized outputs) and triggers an alarm.
Q8: Is redundancy mandatory for SIL 3 applications?
A8: Redundancy is not mandatory but highly recommended to meet diagnostic coverage requirements.
