Technical Specifications
| Parameter | Specification |
|---|---|
| Model | HIMA F3222 |
| Input Channels | 8-channel input for proximity switches (NAMUR, per EN 60947-5-6) |
| Isolation | Safety isolation between inputs and system |
| Sensor Supply Voltage | 7.7 V to 9 V DC |
| Switching Point | 1.65 mA ± 0.2 mA |
| Switching Current Difference | Approx. 0.3 mA |
| Switching Time | Approx. 10 ms |
| Operating Voltage | 5 VDC / 40 mA |
| Additional Supply Voltage | 24 VDC / 75 mA |
| Space Requirement | 4 SU (Standard Units) |
| Dimensions (W x H x D) | 130 mm x 30 mm x 100 mm |
| Weight | 0.25 kg |
| Input Cable Type | LiYY 16 x 0.5 mm² |
| Input Signal Range | High Signal: > 2.1 mA Low Signal: < 1.2 mA |
| Channel Indication | LED display per channel (z4 to z30) |
| Connection Interface | Front cable plug with labeled leads |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of sensors is the HIMA F3222 compatible with?
A1: The F3222 module is designed for proximity switches compliant with the NAMUR standard (EN 60947-5-6).
Q2: Is the F3222 module galvanically isolated?
A2: Yes, the module provides safety isolation between the sensor inputs and the control system.
Q3: What is the input switching point of the module?
A3: The switching point is specified as 1.65 mA with a tolerance of ±0.2 mA.
Q4: What is the required sensor supply voltage range for proper operation?
A4: The sensor supply voltage provided by the module ranges from 7.7 V to 9 V DC.
Q5: How many SU (Standard Units) does the module occupy on the mounting rail?
A5: The F3222 requires 4 SU of space on the DIN rail.
Q6: What type of connection interface is used for input wiring?
A6: The module uses a front cable plug interface with 16-core LiYY 0.5 mm² wires.
Q7: How is the input status indicated on the module?
A7: Each input channel is equipped with an LED indicator showing the high or low signal status.
Q8: Can this module be used in safety-critical applications?
A8: Yes, the F3222 is suitable for use in safety-related applications due to its compliance with NAMUR standards and provision of isolated inputs.
