Technical Specifications
| Parameter | Description |
|---|---|
| Product Type | Digital Input Module |
| System | Planar F System |
| Input Channels | 16 channels |
| Input Type | Digital (Discrete) |
| Signal Voltage Range | 18 to 30 V DC |
| Input Current | Approx. 2.5 mA per channel |
| Isolation | Galvanic isolation per channel |
| Input Delay Time | Typically 5 ms |
| Status Indication | LED per channel |
| Redundancy | Supported (system-dependent) |
| Diagnostic Functions | Short circuit and wire break |
| Operating Temperature | 0 to +60°C |
| Storage Temperature | -40 to +85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Mounting | DIN rail mounting |
| Power Supply | Supplied via system backplane |
| Protection Class | IP20 |
| Dimensions (W x H x D) | 100 x 25 x 120 mm |
| Weight | 0.2 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the HIMA F3216 module?
A1: The F3216 is used to acquire 16 digital input signals for processing in safety-related applications within the HIMA Planar F system.
Q2: Is the F3216 suitable for use in redundant system architectures?
A2: Yes, the module supports redundancy, depending on the system configuration.
Q3: Does the F3216 provide galvanic isolation?
A3: Yes, galvanic isolation is provided between each input channel and the system for reliable operation and noise immunity.
Q4: How are input signal states indicated on the F3216 module?
A4: Each channel is equipped with an LED indicator to show the signal status.
Q5: What kind of diagnostics does the F3216 offer?
A5: The module supports diagnostic functions such as short circuit detection and wire break monitoring.
Q6: What is the standard signal voltage range for digital inputs on this module?
A6: The input voltage range is typically 18 to 30 V DC.
Q7: Can the F3216 operate in harsh industrial environments?
A7: Yes, it is designed for industrial use with a wide temperature range and humidity tolerance.
Q8: What is the mounting method for this module?
A8: The F3216 is designed for DIN rail mounting, ensuring ease of installation and system integration.
