Product Specifications
Below is a detailed table with the technical specifications of the HIMA HIMatrix F1 DI 16 01:
| Specification | Details |
|---|---|
| Product Name | HIMA HIMatrix F1 DI 16 01 Remote I/O Module |
| Dimensions | 152 x 114 x 66 mm |
| Weight | 0.7 kg |
| Digital Inputs | 16 (non-galvanically separated) |
| Pulsed Outputs | 4 (non-galvanically separated) |
| Input Voltage Range | 15 – 30 VDC |
| Switching Time | 250 µs |
| Response Time | ≥ 20 ms |
| Ethernet Interfaces | 2 x RJ-45, 10BASE-T/100BASE-Tx |
| Operating Voltage | 24 VDC (-15% to +20%) |
| Current Input | Max. 0.8 A |
| Protection Class | IP20 |
| Operating Temperature | 0 to +60 °C |
| Storage Temperature | -40 to +85 °C |
| Communication Protocol | safeethernet |
| Mounting Type | DIN rail 35mm |
| Certifications | SIL 3 (IEC 61508, IEC 61511), PL e (EN ISO 13849-1), SIL 4 (EN 50126, EN 50128, EN 50129) |
Product Introduction
The HIMA HIMatrix F1 DI 16 01 is a compact remote I/O module designed for safety-critical automation applications. It features 16 digital inputs and 4 pulsed outputs, ensuring high reliability in industrial settings. The module is certified up to SIL 3 (Safety Integrity Level 3) and is compliant with multiple safety standards, making it an ideal choice for high-demand environments.
The F1 DI 16 01 connects seamlessly with HIMax or HIMatrix controllers via safeethernet, providing secure communication for extending the I/O level. It is particularly suited for industries requiring high availability, fault detection, and emergency stop monitoring.
Applications
The HIMA HIMatrix F1 DI 16 01 is widely used in various industrial applications, including:
- Process Automation – Ensures safe operation in chemical, pharmaceutical, and oil & gas industries.
- Railway Systems – Certified for railway applications (SIL 4) in accordance with EN 50126, EN 50128, and EN 50129.
- Power Plants – Used in power generation and distribution for critical safety functions.
- Manufacturing Plants – Ensures machine safety, emergency stop monitoring, and line control.
- Oil & Gas – Ideal for hazardous environments, supporting ATEX Zone 2 installation.
- Marine and Offshore Applications – Complies with industry standards for marine safety systems.
- Refineries and Petrochemical Plants – Provides high-reliability input monitoring in explosive atmospheres.
Product Advantages
- High Safety Standards – Certified for SIL 3 (IEC 61508, IEC 61511) and SIL 4 (EN 50126, EN 50128, EN 50129).
- Reliable Performance – Features safeethernet communication and robust fault diagnostics.
- Fast Response Time – Ensures quick reaction to critical safety inputs.
- Compact and Durable – Rugged IP20-rated enclosure with a small footprint for easy installation.
- Redundant Communication – Dual RJ-45 Ethernet ports enable secure and redundant network connectivity.
- Integrated Line Monitoring – Detects short circuits, open circuits, and emergency stop failures.
- Wide Temperature Range – Operates between 0 to +60°C, with extended versions available for harsher conditions.
- Seamless Integration – Compatible with HIMax and HIMatrix controllers using SILworX or ELOP II Factory.
- Easy Mounting – Supports DIN rail 35mm mounting for quick installation.
- TÜV Certified – Ensures compliance with the highest international safety standards.
