Product Specifications
The following table outlines the key technical specifications of the HIMA F1201 4X Relay Amplifier Module:
Parameter | Specification |
---|---|
Manufacturer | HIMA |
Model | F1201 |
Type | Relay Amplifier Module |
Number of Relays | 4 |
Voltage Rating | 24V DC |
Current Rating | 6A per relay |
Response Time | <10 ms |
Operating Temperature | -20°C to +60°C |
Storage Temperature | -40°C to +85°C |
Mounting Type | DIN Rail |
Dimensions | 152 x 120 x 75 mm |
Weight | 1.2 kg |
Certifications | CE, ATEX, SIL3, IEC 61508 |
Product Introduction
The HIMA F1201 4X Relay Amplifier Module is an advanced industrial relay module designed for safety-critical applications. It provides four high-performance relays, enabling robust signal amplification and isolation in automation systems.
This module is specifically designed to work within HIMA’s safety systems, ensuring high reliability, fast response times, and adherence to stringent industrial safety standards. It supports 24V DC input voltage and can handle up to 6A per relay, making it suitable for demanding industrial environments.
Built with DIN rail mounting and rugged housing, the F1201 ensures durability and ease of installation in control cabinets. It meets the SIL3 (Safety Integrity Level 3) standard, confirming its capability for high-dependability applications in process automation, power plants, and manufacturing systems.
Product Applications
The HIMA F1201 4X Relay Amplifier Module is used in a variety of industrial applications, including:
-
Process Automation: Provides relay control for critical safety loops in chemical, oil & gas, and pharmaceutical industries.
-
Power Plants: Used for switching and controlling signals in power generation and distribution systems.
-
Manufacturing Systems: Ensures reliable relay operation in automated production lines and robotic systems.
-
Railway and Transportation: Used in safety circuits for train control and railway signaling systems.
-
Oil & Gas Industry: Critical in emergency shutdown (ESD) and fire & gas (F&G) safety systems.
-
Water Treatment Plants: Helps control and monitor pump stations and flow regulation systems.
-
Building Automation: Used in large-scale HVAC and security control systems for commercial and industrial buildings.
Product Advantages
-
High Safety Standard: Compliant with SIL3 (IEC 61508) for maximum safety in industrial applications.
-
Fast Response Time: Switching time of less than 10 ms, ensuring minimal delay in control processes.
-
Robust and Durable: Designed for harsh environments with a temperature range of -20°C to +60°C.
-
Flexible Mounting: Compatible with DIN rail mounting, allowing easy integration into control panels.
-
Compact and Lightweight: With a size of 152 x 120 x 75 mm and a weight of 1.2 kg, it is compact for easy installation.
-
High Load Capacity: Each relay can handle up to 6A, making it suitable for various industrial loads.
-
Reliable Performance: Ensures stable signal transmission with low failure rates.
-
Wide Application Range: Used in diverse industries, including power plants, automation, and transportation.
-
Certified for Safety: Meets CE, ATEX, and IEC 61508 standards, ensuring regulatory compliance.
-
Energy Efficient: Optimized for low power consumption while maintaining high performance.
Latest News about HIMA F1201
- “HIMA Expands Safety Automation Solutions with F1201 Relay Module”
- “New Advances in Industrial Safety: HIMA F1201 Ensures High-Performance Reliability”
- “HIMA F1201 Relay Module Now Certified for ATEX and SIL3 Applications”
- “Enhancing Power Plant Safety with the HIMA F1201 Relay Amplifier”
- “Industrial Automation Leaders Choose HIMA F1201 for Safety-Critical Applications”
Related Models in the Same Series
Here are 10 related models from HIMA that offer similar or complementary functionalities:
Model Number | Description |
---|---|
F1202 | 8X Relay Amplifier Module |
F2201 | Digital Input Module |
F2301 | Digital Output Module |
F7105 | Analog Input Module |
F7126 | Analog Output Module |
F3417A | Safety Controller Module |
F8650X | CPU Module for Safety Systems |
F7131 | Temperature Input Module |
F3221 | Power Supply Module |
F8641 | Communication Interface Module |
Popular HIMA Models
Below are 10 of the most popular HIMA models used across various industries:
Model Number | Description |
---|---|
HIMatrix F35 | Compact Safety Controller |
H41q-HS | High-Performance Safety Controller |
F8650E | Advanced CPU for Safety Applications |
H51q | Modular Safety System |
F7133 | Intrinsically Safe Input Module |
F3236 | Redundant Power Supply Module |
HIMatrix F60 | High-Speed Safety Controller |
F7106 | Universal Analog Input Module |
F3418 | High-Density Digital Input Module |
H41q-ES | Enhanced Safety System Controller |
FAQ
FAQ (Frequently Asked Questions)
Q1: What is the input voltage for the HIMA F1201 Relay Amplifier Module?
A1: The module operates on 24V DC input voltage.
Q2: How many relays are included in the F1201 module?
A2: It contains four (4) relays for signal amplification and switching.
Q3: What is the maximum current each relay can handle?
A3: Each relay can handle up to 6A of current.
Q4: What safety standards does the F1201 comply with?
A4: It is SIL3 (IEC 61508) certified and meets ATEX requirements.
Q5: Can the F1201 be used in hazardous environments?
A5: Yes, it is ATEX-certified for safe operation in hazardous locations.
Q6: What is the response time of the relay module?
A6: The response time is less than 10 ms.
Q7: How is the module mounted?
A7: It is designed for DIN rail mounting for easy installation.
Q8: What is the operating temperature range?
A8: The module operates in temperatures from -20°C to +60°C.
Q9: What are the dimensions and weight of the module?
A9: The dimensions are 152 x 120 x 75 mm, and the weight is 1.2 kg.
Q10: In which industries is the F1201 commonly used?
A10: It is widely used in process automation, power plants, railway systems, oil & gas, and manufacturing industries.
