GE IS220PTCCH1B Mark VIe Series Thermocouple Input Pack

GE IS220PTCCH1B Mark VIe Series Thermocouple Input Pack

Manufacturer:GE Fanuc

Product Number:IS220PTCCH1B

Product Type:Thermocouple Input Pack

Origin:USA

Dimensions:120 x 80 x 40 mm

Weight:0.5kg

Views:24

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/03/IS220PTCCH1B-2-1.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/IS220PTCCH1B-3.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/IS220PTCCH1B-4.jpg
https://www.tilgames.com/wp-content/uploads/2025/03/IS220PTCCH1B.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Overview

The GE IS220PTCCH1B Mark VIe Series Thermocouple Input Pack is a high-performance thermocouple input module designed for industrial applications, particularly in gas and steam turbine control systems. It is part of the GE Speedtronic Mark VIe series, which is renowned for its reliability and advanced diagnostic capabilities. This module is specifically optimized for combustion applications and supports a wide range of thermocouple types and configurations.


Product Parameters

Parameter Specification
Series Mark VIe
Function Thermocouple Input Module
Model Number IS220PTCCH1B
Input Channels 12 combustion-optimized inputs
Cold Junction 1
Supported Thermocouples E, J, K, S, T
Input Range -8 mV to 45 mV
Cable Resistance Limit ≤ 450 ohms
Cable Distance Up to 984 feet (300 meters) from the turbine I/O panel
Redundancy Options Simplex, Duplex, Triple Modular Redundancy (TMR)
Self-Diagnostics Flash memory, RAM, processor hardware, Ethernet port
Power Supply Monitoring Continuous internal monitoring
Dimensions 120 x 80 x 40 mm
Weight 0.5 kg

Product Introduction

The IS220PTCCH1B is a critical component in the GE Speedtronic Mark VIe control system, designed to handle thermocouple inputs for precise temperature monitoring in turbine systems. It supports a variety of thermocouple types (E, J, K, S, T) and can accommodate both grounded and ungrounded configurations. The module is engineered for high reliability, with advanced self-diagnostic features that ensure continuous operation and early fault detection. Its compact design and robust construction make it suitable for harsh industrial environments.


Product Applications

  • Gas Turbine Control Systems: Monitors combustion temperatures to optimize performance and ensure safety.
  • Steam Turbine Control Systems: Provides accurate temperature readings for steam path monitoring.
  • Industrial Process Control: Used in applications requiring precise temperature measurement and control.
  • Power Generation: Ensures efficient and reliable operation of power plants.
  • Oil and Gas: Monitors critical temperatures in upstream and downstream processes.

Product Advantages

  1. High Accuracy: Supports multiple thermocouple types and provides precise temperature readings.
  2. Robust Diagnostics: Includes self-tests for flash memory, RAM, processor hardware, and Ethernet ports.
  3. Flexible Configuration: Compatible with simplex, duplex, and triple modular redundancy setups.
  4. Long-Distance Capability: Can be placed up to 984 feet from the turbine I/O panel.
  5. Wide Input Range: Accommodates mV inputs from -8 mV to 45 mV.
  6. Compact Design: Small form factor (120 x 80 x 40 mm) and lightweight (0.5 kg) for easy integration.
  7. Reliability: Continuous power supply monitoring ensures stable operation.
  8. Versatility: Suitable for both grounded and ungrounded thermocouples.
  9. Industrial Durability: Built to withstand harsh operating conditions.
  10. Compatibility: Integrates seamlessly with the GE Speedtronic Mark VIe control system.
