Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc |
| Series | PACSystems RX3i |
| Model Number | IC694MDL231 |
| Module Type | Discrete Input Module |
| Input Type | Positive Logic |
| Input Voltage | 24 VDC nominal |
| Input Voltage Range | 0 to 30 VDC |
| Number of Inputs | 16 points |
| Input Characteristics | Sourcing input module with internal power distribution |
| Input Current at Rated Voltage | 7 mA typical at 24 VDC |
| Isolation | 250 VAC continuous; group to backplane and between groups |
| Group Isolation | Two isolated groups (8 points per group) |
| Input Response Time | Off to On: 1 ms; On to Off: 1 ms |
| LED Indicators | Yes, individual input status indicators |
| Backplane Current Consumption | 80 mA at 5 VDC |
| Environmental Protection | Conformal coated (optional) |
| Dimensions (W x H x D) | 34 x 145 x 140 mm |
| Weight | 0.37 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What voltage is required for the IC694MDL231 module?
A1: The module is designed for 24 VDC nominal input, with an operational range from 0 to +30 VDC.
Q2: How many input points are available on the IC694MDL231?
A2: The module provides 16 discrete input points.
Q3: Can the IC694MDL231 module detect low-level voltages?
A3: The minimum on-state voltage is 11 VDC, and the off-state threshold is 5 VDC, making it unsuitable for very low-level detection.
Q4: What is the typical current drawn by each input?
A4: Each input typically draws 7 mA at 24 VDC.
Q5: How is electrical isolation managed in this module?
A5: The module provides 250 VAC continuous isolation (1500 VAC for 1 second) between the field side and backplane, as well as between input groups.
Q6: Is input filtering configurable on the IC694MDL231?
A6: Yes, the module includes configurable filtering, with a default setting of 1 ms.
Q7: Are LED indicators provided for input status monitoring?
A7: Yes, there is one green LED indicator per input point, providing visual status indication.
Q8: Can this module be installed in any RX3i rack slot?
A8: It can be installed in any slot except the CPU and power supply slots.
