GE IC693CPU323 10-Slot Base Turbo CPU Overview
The IC693CPU323 is a robust and high-performance CPU from GE’s Series 90-30 PLC line. Designed for industrial control applications, it combines the versatility of a 10-slot base with an embedded CPU, offering excellent processing speed and memory for a variety of automation needs. The unit’s main features are its compact size, efficient processing speed, and reliable performance in harsh environments.
Key Features of IC693CPU323
-
Processor Type: The unit uses an 80188 processor, running at 10 MHz, which delivers reliable and efficient performance.
-
User Program Memory: The maximum user program memory is 12 Kbytes (6K bytes prior to release 7), which allows ample space for controlling complex processes.
-
Scan Time: The CPU performs at a typical scan rate of 0.6 milliseconds per 1K of logic (boolean contacts), ensuring fast response times.
-
Built-in Ports: Includes one built-in port to support SNP slave and SNP-X slave protocols, enhancing communication flexibility with other devices.
-
Input/Output Points: Supports up to 320 discrete input points (%I) and 320 discrete output points (%Q), offering robust control for large systems.
-
Operating Temperature: Designed to work in temperatures ranging from 0 to 60°C (32 to 140°F), making it suitable for various industrial environments.
Product Specifications
| Specification | Details |
|---|---|
| Product Model | IC693CPU323 |
| Base Type | 10-slot base with embedded CPU |
| User Program Memory | 12 Kbytes (6K bytes prior to release 7) |
| Processor Speed | 10 MHz |
| Processor Type | 80188 |
| Typical Scan Rate | 0.6 milliseconds per 1K of logic |
| Discrete Input Points | 320 points (%I) |
| Discrete Output Points | 320 points (%Q) |
| Discrete Global Memory | 1280 bits (%G) |
| Internal Coils | 1024 bits (%M) |
| Temporary Coils | 256 bits (%T) |
| System Status References | 128 bits (%S, %SA, %SB, %SC – 32 bits each) |
| Register Memory | 1024 words (%R) |
| Analog Inputs | 64 words (%AI) |
| Analog Outputs | 32 words (%AQ) |
| Built-in Communication Ports | 1 (for SNP and SNP-X slave protocols) |
| Battery-backed Clock | No |
| Interrupts | No |
| Storage Type | RAM, with optional EPROM or EEPROM |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Dimensions | 130 x 428 x 142 mm |
| Weight | 1.4 kg |
Product Advantages
-
High Speed: The CPU’s fast processing speed allows for efficient control of complex automation processes with minimal delay.
-
Compact Design: With dimensions of 130 x 428 x 142 mm and weighing only 1.4 kg, this module can be easily integrated into systems with limited space.
-
Flexible Communication: The built-in ports and support for protocols like SNP slave and SNP-X slave allow for seamless integration with other devices in your automation system.
-
Scalable I/O: The unit offers significant I/O points, supporting both discrete and analog I/O, which is essential for large-scale systems.
-
Reliability: The unit is built for use in harsh environments, with an operating temperature range of 0 to 60°C, ensuring consistent performance under varying conditions.
Product Applications
-
Industrial Automation: Used in controlling and monitoring machinery, assembly lines, and manufacturing processes.
-
Process Control: Ideal for process control applications that require reliable input and output handling, such as in chemical, oil, and gas industries.
-
Energy Management: Can be used in energy management systems, providing real-time monitoring and control.
-
Building Automation: The flexibility of the I/O points allows this product to be used in building management systems for HVAC and lighting control.
Recommended Related Models
| Model | Description | Key Features |
|---|---|---|
| IC693CPU320 | 10-Slot Base CPU | 8K memory, 10 MHz processor, 320 I/O points |
| IC693CPU331 | 5-Slot Base CPU with enhanced features | 5-slot base, faster scan rate, 6K program memory |
| IC693CPU340 | High-speed CPU | 12K memory, 32-bit processor, 480 I/O points |
| IC693CPU350 | Advanced 10-slot CPU | 10-slot base, 64-bit processing, enhanced communication |
| IC693CPU360 | Dual CPU for redundancy | Supports dual processors for high availability |
| IC693CPU370 | High-performance processor with 128K memory | 128K memory, 1.5 MHz processor, extended I/O support |
Recommended GE Popular Models
| Model | Description | Key Features |
|---|---|---|
| IC693PWR321 | Power Supply for 90-30 PLC | 24V DC input, 10A output, 130W power output |
| IC693MDL230 | Discrete Input Module | 32 inputs, 24V DC, 10-30V DC voltage range |
| IC693MDL340 | Discrete Output Module | 32 outputs, 24V DC, 0.5A current per point |
| IC693ALG223 | Analog Input Module | 8 analog inputs, 0-10V or 4-20mA input range |
| IC693CMM311 | Communication Module for Ethernet | Supports Ethernet/IP, 10/100 Mbps |
| IC693BRR401 | Redundant Power Supply | Dual redundant power inputs, 24V DC |
FAQ
FAQs for IC693CPU323
-
Q: What is the maximum user program memory for the IC693CPU323? A: The IC693CPU323 supports a maximum of 12K bytes of user program memory.
-
Q: How fast is the CPU scan rate for this model? A: The typical scan rate is 0.6 milliseconds per 1K of logic (boolean contacts).
-
Q: What is the operating temperature range for the IC693CPU323? A: The operating temperature range is from 0 to 60°C (32 to 140°F).
-
Q: Does the IC693CPU323 support Ethernet communication? A: Yes, it supports Ethernet through optional communication modules.
-
Q: How many discrete input and output points does the IC693CPU323 support? A: It supports up to 320 discrete input points (%I) and 320 discrete output points (%Q).
-
Q: What is the maximum number of analog inputs and outputs supported? A: The IC693CPU323 can support up to 64 analog input words (%AI) and 32 analog output words (%AQ).
-
Q: Does the IC693CPU323 have a built-in battery-backed clock? A: No, this unit does not feature a battery-backed clock.
-
Q: Is the IC693CPU323 compatible with all GE Series 90-30 modules? A: Yes, the IC693CPU323 is fully compatible with other Series 90-30 modules, providing seamless integration for large automation systems.
