GE IC693ALG223 Series 90-30 PLC Analog Current Input Module

GE IC693ALG223 Series 90-30 PLC Analog Current Input Module

Manufacturer:GE Fanuc

Product Number:IC693ALG223

Product Type:Analog Current Input Module

Origin:USA

Dimensions:51 x 127 x 127 mm

Weight:0.458 kg

Views:3

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/04/IC693ALG223-3-1.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/IC693ALG223-2.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/IC693ALG223-4.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/IC693ALG223.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

GE IC693ALG223 Series 90-30 PLC Analog Current Input Module

Product Overview:

The GE IC693ALG223 Series 90-30 PLC Analog Current Input Module is designed to provide precise analog current measurements for industrial control systems. It offers 16 single-ended channels, which can be configured for various input ranges. This module is ideal for applications that require high accuracy and reliability in monitoring analog current inputs, such as process control and automation systems.

Product Parameters:

Below is a detailed table of the key specifications for the IC693ALG223 module:

Parameter Value
Number of Channels 1 to 16 (selectable)
Input Current Ranges 0 to 20 mA, 4 to 20 mA, 4 to 20 mA Enhanced
Calibration 4 μA per count on 4 to 20 mA range, 5 μA per count on 0 to 20 mA and 4 to 20 mA Enhanced
Update Rate 6 ms
Resolution (4–20 mA) 4 μA (4 μA/bit)
Resolution (0–20 mA) 5 μA (5 μA/bit)
Resolution (4–20 mA Enhanced) 5 μA (5 μA/bit)
Absolute Accuracy ±0.25% of full scale at 25°C, ±0.5% over specified temperature range
Linearity <1 LSB from 4 to 20 mA (4–20 mA range), <1 LSB from 100 μA to 20 mA (0–20 mA and 4–20 mA Enhanced ranges)
Isolation (Field to Backplane) 250 VAC continuous, 1500 VAC for 1 minute
Common Mode Voltage 0 V (single-ended channels)
Cross-Channel Rejection > 70 dB from DC to 1 kHz
Input Impedance 250 Ω
Input Low Pass Filter Response 19 Hz
External Supply Voltage Range 20 to 30 VDC
External Supply Voltage Ripple 10%
Internal Power Consumption 120 mA from the +5 VDC bus, 65 mA from external 24 VDC
Module Dimensions 51 x 127 x 127 mm
Module Weight 0.458 kg

Product Features:

  • 16 Single-ended Channels: Allows the module to handle a wide range of input signals.

  • Selectable Current Ranges: Provides flexibility with three current ranges: 0-20 mA, 4-20 mA, and 4-20 mA Enhanced.

  • Alarm Limits: High and Low alarm limits can be set for each channel to monitor abnormal conditions.

  • Enhanced Fault Detection: The 4-20 mA Enhanced range allows for open-wire fault detection, improving system reliability.

  • Fast Update Rate: 6 ms update rate ensures quick response times for dynamic systems.

  • Modular Design: The module is designed to fit easily into RX3i and Series 90-30 racks.

Product Advantages:

  • High Accuracy: The module’s high accuracy of ±0.25% ensures precise current measurements for critical applications.

  • Versatile Configuration: The ability to select different input ranges and set alarm thresholds provides customization for specific system needs.

  • Reliable Performance: With 250 VAC isolation and robust protection features, the module is built for long-term industrial use.

  • Ease of Integration: Compatible with RX3i and Series 90-30 PLC systems, making it suitable for a wide variety of industrial applications.

Applications: The IC693ALG223 module is commonly used in:

  • Process Control: Monitoring and controlling industrial processes with varying current inputs.

  • Automation Systems: Integration in automation systems requiring precise analog signal measurement.

  • Energy Management: Used in systems where real-time monitoring of power and energy consumption is essential.

Latest Reports:

  • “IC693ALG223 Module Optimizes Industrial Process Control in Harsh Environments”

  • “GE’s Series 90-30 PLC System: Advancements in Analog Input Modules”

  • “New Features in GE IC693ALG223 Enhance Fault Detection Capabilities”


Recommended Models from the Series:

Here are six related models from the same Series:

Model Number of Channels Input Range Update Rate Resolution
IC693ALG223 16 0 to 20 mA, 4 to 20 mA 6 ms 4 μA/bit
IC694ALG223 16 0 to 20 mA, 4 to 20 mA 6 ms 5 μA/bit
IC693ALG213 8 0 to 10 V, ±10 V 6 ms 2 mV/bit
IC693ALG223G 16 0 to 20 mA, 4 to 20 mA 6 ms 4 μA/bit
IC694ALG221 16 ±10 V, 0 to 10 V 6 ms 2 mV/bit
IC693ALG243 16 4 to 20 mA, 0 to 20 mA 6 ms 4 μA/bit

Popular GE Models:

Below are six popular GE models for various industrial applications:

Model Number of Channels Input Range Update Rate Resolution Dimensions
IC693ALG222 8 4 to 20 mA 6 ms 4 μA/bit 51 x 127 x 127 mm
IC693ALG221 16 ±10 V, 0 to 10 V 6 ms 2 mV/bit 51 x 127 x 127 mm
IC693ALG210 8 ±10 V, 0 to 10 V 6 ms 2 mV/bit 51 x 127 x 127 mm
IC694ALG228 16 0 to 20 mA 6 ms 4 μA/bit 51 x 127 x 127 mm
IC693ALG226 8 4 to 20 mA 6 ms 4 μA/bit 51 x 127 x 127 mm
IC694ALG227 8 ±10 V, 0 to 10 V 6 ms 2 mV/bit 51 x 127 x 127 mm
FAQ

FAQ (Frequently Asked Questions):

Q1: What is the maximum number of channels that can be configured on the IC693ALG223 module?
A1: The module allows configuration of up to 16 channels.

Q2: What input ranges are supported by this module?
A2: The module supports the following input ranges: 0 to 20 mA, 4 to 20 mA, and 4 to 20 mA Enhanced.

Q3: Can the IC693ALG223 module detect open-wire faults?
A3: Yes, the 4 to 20 mA Enhanced range supports open-wire fault detection.

Q4: What is the resolution of the module at the 4 to 20 mA range?
A4: The resolution is 4 μA (4 μA/bit) at the 4 to 20 mA range.

Q5: Is the IC693ALG223 module compatible with Series 90-30 and RX3i systems?
A5: Yes, the module is compatible with both Series 90-30 and RX3i PLC systems.

Q6: What is the update rate of the IC693ALG223 module?
A6: The update rate is 6 ms.

Q7: What power supply is required for the IC693ALG223 module?
A7: The module requires a 5 VDC bus from the backplane and a 24 VDC external power supply.

Q8: How is the module calibrated?
A8: The module is factory-calibrated to 4 μA per count on the 4 to 20 mA range and 5 μA per count on the other ranges.
