GE IC693ALG222-HB Analog Current Input Module

GE IC693ALG222-HB Analog Current Input Module

Manufacturer:GE Fanuc

Product Number:IC693ALG222-HB

Product Type:Analog Current Input Module

Origin:USA

Dimensions:174 x 114 x 39 mm

Weight:0.41 kg

Views:6

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24

Send Inquiry
Description
FAQ
Products Description
https://www.tilgames.com/wp-content/uploads/2025/04/IC693ALG222-HB-1.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/IC693ALG222-HB-4.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/IC693ALG222-HB-2.jpg
https://www.tilgames.com/wp-content/uploads/2025/04/IC693ALG222-HB-3.jpg
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

GE IC693ALG222-HB Analog Current Input Module: Detailed Overview

Product Overview:

The GE IC693ALG222-HB is a highly efficient 16-channel analog voltage input module designed for the Series 90-30 PLC. It converts analog voltage signals into digital values to be used in industrial applications. The module can handle up to 16 single-ended or 8 differential input channels, providing flexibility in measurement configurations. The module is widely used in environments that require high precision and quick updates for analog signal processing.


Product Specifications:

Parameter Specification
Model IC693ALG222-HB
Channels 16 single-ended or 8 differential inputs
Input Voltage Range 0V to 10V (unipolar) or -10V to +10V (bipolar)
Calibration Factory calibrated (2.5 mV/count for unipolar, 5 mV/count for bipolar)
Update Rate 6 ms (single-ended), 3 ms (differential)
Resolution 2.5 mV (unipolar), 5 mV (bipolar)
Accuracy ± 0.25% of full scale at 25°C, ± 0.5% over temperature range
Isolation 1500 V isolation between field and logic sides
Power Consumption 112 mA (maximum) from backplane +5 VDC, 41 mA from +24 VDC supply
Input Impedance >500K ohms (single-ended), >1M ohms (differential)
Cross-Channel Rejection > 80 dB from DC to 1 kHz
Common Mode Voltage ± 11V (bipolar range)
Dimensions 174 mm x 114 mm x 39 mm
Weight 0.41 kg

Product Features:

  • High Channel Density: Supports up to 16 channels for flexible signal measurement in both single-ended and differential modes.

  • Selectable Input Ranges: Offers both unipolar (0-10V) and bipolar (-10V to +10V) ranges for greater measurement flexibility.

  • Precision: Factory-calibrated to ensure accurate data processing with high resolution of 2.5mV per count (unipolar).

  • Real-time Processing: The module ensures rapid data acquisition with a high update rate, making it ideal for time-sensitive applications.

  • Wide Isolation: With 1500 V isolation, the module protects the system from electrical noise and ensures safe operation in industrial environments.

  • Flexible Integration: It can be installed in any I/O slot of a Series 90-30 PLC system, making it a versatile choice for various industrial control applications.


Product Advantages:

  • Enhanced Accuracy: The factory calibration ensures that the module provides highly accurate analog to digital conversions with minimal error.

  • Modular Configuration: The ability to configure 1-16 channels in single-ended mode or 1-8 in differential mode offers flexibility for diverse applications.

  • Alarm Functions: The module includes programmable high and low alarm limits for each channel, providing real-time monitoring and control.

  • Ease of Integration: Easily integrates with the Series 90-30 PLC system using standard configuration tools like Logicmaster or the Hand-Held Programmer.

  • Wide Operating Temperature Range: Suitable for use in various industrial environments, the module maintains accuracy across a broad temperature range.


Applications:

  • Industrial Process Control: Used in plants for monitoring and controlling processes that require precise voltage measurements.

  • Machine Monitoring: Ideal for measuring analog signals from sensors in automated machines.

  • Energy Management: Helps in measuring input voltages from energy meters for monitoring power consumption.

  • Environmental Monitoring: Can be used to collect data from sensors measuring environmental parameters such as temperature and humidity.

  • Test and Measurement: Employed in laboratory settings for capturing precise voltage measurements in scientific experiments.


Latest Reports:

  • Report Title: “Enhancing PLC Efficiency with Advanced Analog Input Modules”

  • Report Title: “Real-Time Data Acquisition Systems in Industrial Control”

  • Report Title: “Optimizing Voltage Input Modules for High-Performance Automation Systems”


Related Models from the Same Series:

Model Channels Voltage Range Power Consumption Resolution Update Rate
IC693ALG223 8 Differential -10V to +10V 112 mA (max) from +5V 5 mV (bipolar) 3 ms
IC693ALG224 16 Single-ended 0V to 10V (unipolar) 112 mA (max) from +5V 2.5 mV (unipolar) 6 ms
IC693ALG225 16 Differential -10V to +10V (bipolar) 112 mA (max) from +5V 5 mV (bipolar) 3 ms
IC693ALG226 8 Single-ended 0V to 10V (unipolar) 112 mA (max) from +5V 2.5 mV (unipolar) 6 ms
IC693ALG227 16 Single-ended 0V to 10V (unipolar) 112 mA (max) from +5V 2.5 mV (unipolar) 6 ms
IC693ALG228 8 Differential -10V to +10V (bipolar) 112 mA (max) from +5V 5 mV (bipolar) 3 ms

Popular GE Models:

Model Channels Voltage Range Power Consumption Resolution Update Rate
IC693PWR330 1 (Power Supply) 24 VDC 300 mA N/A N/A
IC693ALD310 8 0 to 10V (unipolar) 112 mA (max) from +5V 2.5 mV (unipolar) 6 ms
IC693PWR334 1 (Power Supply) 24 VDC 500 mA N/A N/A
IC693CMM311 1 (Communication Module) N/A 350 mA N/A N/A
IC693MDL240 16 24 VDC (Digital Output) 100 mA N/A N/A
IC693AI810 8 0-10V 180 mA 2.5 mV (unipolar) 6 ms
FAQ

FAQs:

Q1: What is the voltage range of the GE IC693ALG222-HB module?
A1: The module supports both unipolar (0V to 10V) and bipolar (-10V to +10V) voltage ranges.

Q2: How many input channels can be configured on the IC693ALG222-HB module?
A2: The module supports 16 single-ended input channels or 8 differential input channels.

Q3: What is the update rate of the IC693ALG222-HB module?
A3: The update rate is 6 ms for single-ended mode and 3 ms for differential mode.

Q4: How accurate is the GE IC693ALG222-HB module?
A4: The module has an accuracy of ±0.25% of full scale at 25°C and ±0.5% over the specified operating temperature range.

Q5: Can the voltage range be configured per channel?
A5: Yes, the voltage range can be configured on a per-channel basis.

Q6: How much power does the IC693ALG222-HB module consume?
A6: The module consumes a maximum of 112 mA from the 5V bus and 41 mA from the 24V DC supply.

Q7: What is the weight of the IC693ALG222-HB module?
A7: The module weighs 0.41 kg.

Q8: Can the IC693ALG222-HB module be installed in any slot of a Series 90-30 PLC system?
A8: Yes, the module can be installed in any I/O slot of a 5 or 10-slot baseplate in a Series 90-30 PLC system.
