Product Specifications
| Parameter | Value |
|---|---|
| Product Name | IC200ERM002A VersaMax Expansion Receiver Module |
| Expansion Type | Receiver |
| Distance | Up to 2460 feet, up to 50 feet for non-isolated receiver |
| Current Consumption (5V Backplane) | 430 mA |
| Current Consumption (3.3V Backplane) | 20 mA |
| LED Indicators | PWR, EXP RX, SCAN |
| Dimensions (W x H x D) | 66.8mm x 128mm x 69.1mm |
| Weight | 0.222 kg |
FAQ
FAQ
Q1: What is the IC200ERM002A?
A1: The IC200ERM002A is an expansion receiver module in the GE VersaMax series that allows additional I/O units to be added to a VersaMax PLC system.
Q2: What is the maximum distance supported by IC200ERM002A?
A2: IC200ERM002A supports up to 2460 feet of connection distance, with a maximum of 50 feet for non-isolated receivers.
Q3: What are the power requirements for IC200ERM002A?
A3: The module requires 430 mA current from a 5V backplane and 20 mA current from a 3.3V backplane.
Q4: What LED indicators are available on IC200ERM002A?
A4: IC200ERM002A has PWR LED, EXP RX LED, and SCAN LED indicators that show power status, expansion bus status, and whether the CPU is scanning the expansion I/O.
Q5: What are the dimensions and weight of IC200ERM002A?
A5: The dimensions are 66.8mm x 128mm x 69.1mm, and the weight is 0.222 kg.
Q6: Does IC200ERM002A support isolation?
A6: IC200ERM002A is a non-isolated version of the receiver module. If isolation is required, the IC200ERM001 module should be used.
Q7: What is the maximum number of I/O points supported by IC200ERM002A?
A7: IC200ERM002A can support up to 8 modules per expansion rack, with a maximum of 8 I/O points per module.
Q8: What types of systems is IC200ERM002A compatible with?
A8: IC200ERM002A is compatible with GE VersaMax PLCs and I/O stations, providing modular expansion capabilities to enhance the system.
