Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Analog Input Module |
| Module Series | PACSystems RX3i |
| Number of Input Channels | 4 Differential or 8 Single-Ended |
| Input Signal Ranges | ±10V, ±5V, 0–5V, 0–10V, 0–20 mA, 4–20 mA |
| Resolution | 12 bits |
| Conversion Type | Successive Approximation |
| Conversion Time | 1 ms per channel (maximum) |
| Input Impedance (Voltage) | ≥ 100 kΩ |
| Input Impedance (Current) | 250 Ω (via internal precision resistor) |
| Common Mode Voltage Range | ±10V max |
| Accuracy | ±0.1% of Full Scale |
| Isolation | 1500V RMS (channel-to-backplane) |
| Channel Configuration | Software-selectable |
| Calibration | Factory-calibrated, no user adjustment |
| Power Supply Requirement | 5V DC, 200 mA (typical) |
| Dimensions (W x H x D) | 34 × 145 × 140 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many channels does the HE693ADC409 module support?
A1: The module supports up to 8 single-ended or 4 differential analog input channels.
Q2: What type of signals can this module accept?
A2: It can handle voltage signals of ±10V, ±5V, 0–5V, 0–10V and current signals of 0–20 mA or 4–20 mA.
Q3: Is the module capable of both voltage and current inputs on the same channel?
A3: No, each channel must be configured for either voltage or current input based on application requirements.
Q4: How accurate is the HE693ADC409 module?
A4: It offers an accuracy of ±0.1% of the full-scale range under normal operating conditions.
Q5: Is external calibration required for this module?
A5: No, the module is factory-calibrated and does not require user calibration.
Q6: What is the input impedance when using current input mode?
A6: The input impedance is 250 ohms due to an internal precision resistor.
Q7: Does this module provide electrical isolation between the inputs and the backplane?
A7: Yes, the module provides 1500V RMS isolation from input channels to the backplane.
Q8: What is the conversion time per channel for data acquisition?
A8: The conversion time is approximately 1 millisecond per channel.
