Technical Specifications
| Parameter | Description |
|---|---|
| Measuring Principle | Electro-mechanical conversion for absolute vibration measurement |
| Sensitivity | 28.5 mV/(mm/s) ±5 % (20°C, 80 Hz, 100 kΩ load) |
| Damping Factor | 0.56 (20°C, 100 kΩ load) |
| Frequency Range | 10 Hz to 1000 Hz |
| Natural Frequency | 8.0 Hz ±1.5 Hz (20°C, 100 kΩ load) |
| Transverse Sensitivity | 0.1 @ 80 Hz |
| Operating Temperature Range | -20°C to +200°C (without connector) |
| Relative Humidity | 0% to 100% (non-condensing in housing and plug) |
| Protection Class | IP65 |
| Dimensions | 78 × 58 mm |
| Weight | 0.93 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What environments is the Epro PR9268/302-100 Machinery Health Sensor suitable for?
A1: The sensor is suitable for various harsh environments, capable of withstanding temperatures up to 200°C, with an IP65 protection rating for water and dust resistance.
Q2: What is the frequency range of the sensor?
A2: The sensor’s frequency range is 10 Hz to 1000 Hz, making it suitable for various vibration measurement applications.
Q3: How sensitive is the sensor?
A3: The sensitivity of the sensor is 28.5 mV/(mm/s) ±5 % at 20°C and 80 Hz, with a 100 kΩ load.
Q4: What are the dimensions of the Epro PR9268/302-100?
A4: The sensor’s dimensions are 78 × 58 mm, making it compact and suitable for a variety of installation spaces.
Q5: What is the weight of the sensor?
A5: The weight of the sensor is 0.93 kg, making it stable for installation and use.
Q6: What is the maximum acceleration for the PR9268/302-100?
A6: The maximum permissible acceleration is 10 g (continuous) and 20 g (short-term).
Q7: Does the sensor require regular maintenance?
A7: The sensor does not require regular maintenance during normal operation. In case of malfunction, simple tests like resistance and insulation resistance checks can be performed.
Q8: How do I troubleshoot the sensor?
A8: Troubleshooting can be done by checking the sensor’s resistance, insulation resistance, and signal generation. If needed, professional repair services should be contacted.
