Technical Specifications
| Parameter | Value |
|---|---|
| Dimensions | 78 × 58 mm |
| Weight | 0.93 kg |
| Frequency Range | 4 Hz to 1000 Hz |
| Natural Frequency | 4.5 Hz ±11.1% (at 20°C, 100 kΩ load) |
| Sensitivity | 28.8 mV/(mm/s) ±2.5% (at 20°C, 100 kΩ load) |
| Damping Factor | 0.56 (at 20°C, 100 kΩ load) |
| Resistance Measuring Coil | 375 Ω ±5% |
| Insulation Resistance | >1 MΩ (test voltage 500 V AC) |
| Inductance | <90 mH |
| Capacity Against Housing | <1.2 nF |
| Maximum Lifting Current | 1.8 mA (for deviation from nominal measuring direction) |
FAQ
FAQ
Q1: What is the operating temperature range of the PR9268 sensor?
-
A1: The operating temperature range for the transducer without the connector is -20°C to +100°C, with short-term usage (less than 4 hours) up to 120°C.
Q2: What is the weight of the PR9268 sensor?
-
A2: The net weight, including cable, connector, and plug, is approximately 930 g. The transducer alone weighs around 260 g, and with packing, the total weight is approximately 1200 g.
Q3: What is the radiation resistance of the PR9268 sensor?
-
A3: The PR9268 sensor with RAD type has a radiation resistance of 8×10⁵ Gy.
Q4: What is the protection class for the PR9268?
-
A4: The protection class for the PR9268 sensor varies. For the 20x-x00 and 30x-x00 types, the protection class is IP 55, while for the 60x-000 and 70x-000 types, it is IP 65.
Q5: Can the PR9268 sensor be used in hazardous locations?
-
A5: Yes, the PR9268 sensor is certified for use in hazardous locations with intrinsic safety protection (Ex ia IIC T6…T4 Ga for 20x-x00 and 30x-x00 types, and Ex ib IIC T4…T3 Gb for 60x-000 and 70x-000 types).
Q6: What are the maximum deviation limits for the measuring direction?
-
A6: For the PR9268/20x-xxx and PR9268/30x-xxx models, the maximum deviation from the nominal measuring direction is ±30° without sinking current and ±60° with sinking current. For the PR9268/60x-000 and PR9268/70x-000 models, the deviation is ±30° without sinking current and ±60° with sinking current.
Q7: What is the maximum permissible acceleration for the sensor?
-
A7: The maximum permissible acceleration in the measuring direction is 10 g peak-peak continuously and 20 g peak-peak for short times. In the transverse direction, the permissible acceleration is 2 g peak-peak.
Q8: What is the sensor’s damping factor?
-
A8: The damping factor of the PR9268 sensor is 0.56 at 20°C with a 100 kΩ load.
