Product Description
The Emerson VE4003S5B1 KJ3002X1-BG2 12P1731X082 is a high-performance Analog Input Card designed for use in the DeltaV™ distributed control system (DCS). It provides reliable and accurate signal acquisition from analog field devices such as transmitters and sensors. This module is engineered for seamless integration with the DeltaV system architecture and supports thermocouple-type signals. Known for its robust construction and diagnostic features, it is well-suited for industrial process control applications that require dependable analog signal monitoring.
This model is specifically designed to handle thermocouple inputs and is compatible with DeltaV S-series and M-series controllers, enabling flexible deployment across various system architectures. Built to comply with rigorous industrial standards, it delivers exceptional performance in demanding environments.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | VE4003S5B1 |
| Part Number | KJ3002X1-BG2 |
| Catalog Number | 12P1731X082 |
| Type | Analog Input Card |
| Supported Input Type | Thermocouple (J, K, E, T, B, R, S, N) |
| Channels | 8 Analog Inputs |
| Resolution | 16-bit |
| Input Range | -5 mV to +75 mV (based on thermocouple type) |
| Input Impedance | >10 MΩ |
| Accuracy | ±0.1% of span |
| Update Rate | 250 ms/channel |
| Isolation | Channel-to-channel and channel-to-ground |
| Redundancy | Yes (with redundant cards) |
| Temperature Compensation | Cold junction compensated |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% RH non-condensing |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.281 kg |
| Certifications | CE, CSA, ATEX, FM Class I Div 2, RoHS |
Product Features
-
Supports multiple thermocouple types (J, K, E, T, B, R, S, N) for high flexibility in process monitoring.
-
High-resolution 16-bit analog-to-digital conversion ensures accurate temperature measurement.
-
Fully redundant design for increased reliability and fault tolerance.
-
Integrated cold junction compensation improves thermocouple measurement accuracy.
-
Advanced diagnostics monitor line integrity, open wire detection, and internal errors.
-
Plug-and-play functionality within the DeltaV system allows for fast installation and commissioning.
-
Channel-to-channel isolation enhances protection and prevents signal interference.
-
Wide operating temperature range suitable for harsh environments.
Product Advantages
-
System Compatibility: Seamlessly integrates with DeltaV S-series and M-series controllers, enhancing scalability and operational consistency.
-
Precision and Stability: Provides highly accurate readings even in fluctuating temperature environments, minimizing errors in process control.
-
Robust Engineering: Designed to operate reliably in extreme industrial settings with high vibration, temperature variation, and humidity.
-
Diagnostics Support: Increases system availability and maintenance efficiency with real-time fault detection and status feedback.
-
Space-Saving Design: Compact form factor (107 x 41 x 105 mm) fits efficiently into crowded control cabinets.
-
Lightweight Construction: Weighs only 0.281 kg, making handling and replacement easy and quick.
Product Applications
-
Chemical Processing Plants: For monitoring and controlling process temperatures using thermocouple inputs.
-
Petrochemical Refineries: Ideal for critical temperature sensing in high-temperature processing units.
-
Power Generation Facilities: Used in turbine monitoring, boiler control, and environmental compliance systems.
-
Pharmaceutical Manufacturing: Maintains precision temperature control in sensitive production environments.
-
Food and Beverage Industry: Ensures consistency in heat treatment, fermentation, and refrigeration processes.
-
Water and Wastewater Treatment: Provides reliable temperature data for biological and chemical treatment processes.
