Product Specifications
| Parameter | Value |
|---|---|
| Product Model | VE4001S2T2B4 |
| Type | Discrete Input (DI) Card |
| Input Type | Dry Contact |
| Number of Channels | 32 |
| Input Voltage Range | 24V DC |
| Input Impedance | Approx. 5 kΩ |
| Detection Threshold (ON) | > 2 mA |
| Detection Threshold (OFF) | < 0.25 mA |
| Wetting Voltage | 24V DC |
| Isolation | Each channel optically isolated; tested to 1500V DC |
| Field Circuit Power | 150 mA at 24V DC |
| LocalBus Current (12V DC) | 50 mA typical, 75 mA maximum |
| Terminal Block Type | 32-screw termination block |
| Redundancy Support | No (VE4001S2T2B4 is simplex; use VE4031S2T2B4 for redundancy) |
| Dimensions (H x W x D) | 107 x 41 x 105 mm |
| Weight | 0.068 kg |
| Operating Temperature | -40 to +70°C |
| Storage Temperature | -40 to +85°C |
| Relative Humidity | 5 to 95%, non-condensing |
| Vibration Resistance | 1 mm peak-to-peak (5–16 Hz); 0.5 g (16–150 Hz) |
| Shock Resistance | 10 g, ½ sine wave, 11 ms |
| Protection Rating | IP20 |
| Certifications | CE, FM, CSA, ATEX, IECEx, DNV, ABS |
| Mounting | On DeltaV M-series I/O carrier |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of field devices are compatible with the VE4001S2T2B4?
A1: This module is designed for dry contact devices operating at 24V DC, including mechanical switches and many NAMUR sensors.
Q2: Does the VE4001S2T2B4 support redundancy?
A2: No, VE4001S2T2B4 is a simplex card. For redundant applications, use VE4031S2T2B4 with the appropriate terminal block.
Q3: What is the difference between the VE4001S2T2B4 and VE4001S2T2B1?
A3: VE4001S2T2B4 is a 32-channel card using a 32-screw terminal block. VE4001S2T2B1 is an 8-channel card with different wiring and form factor.
Q4: What is the wetting voltage, and why is it important?
A4: The wetting voltage is 24V DC, which ensures reliable activation of contact devices by preventing oxidation buildup on the contact surfaces.
Q5: Can the VE4001S2T2B4 detect pulses from field devices?
A5: Yes, it supports pulse count mode for input frequencies below 75 Hz, suitable for applications like flow metering or event logging.
Q6: What diagnostics does the module support?
A6: It includes internal error indication and channel isolation. Combined with the DeltaV diagnostics explorer, it enables real-time health monitoring.
Q7: How should I wire the terminal block?
A7: VE4001S2T2B4 uses a 32-screw terminal block with a shared common return. Pre-wiring is possible before the card installation.
Q8: Is this card suitable for hazardous areas?
A8: Yes, it meets FM, ATEX, and IECEx standards for Class I, Div 2 (Zone 2) installations. Always follow proper installation practices in such areas.
