Product Introduction
The Emerson KJ3222X1-BA1 is a high-performance Analog Input Module designed for the DeltaV distributed control system. It provides precise analog signal acquisition and conversion, making it ideal for industrial automation and process control applications. The module is engineered to operate in harsh environments, ensuring reliability and accuracy in critical operations.
Product Specifications
| Parameter | Specification |
|---|---|
| Local Bus Power | 12 VDC at 150 mA |
| Bussed Field Power | 24 VDC at 300 mA |
| Field Circuit | 24 VDC at 30 mA/Ch. |
| Ambient Temperature | -40 °C to +70 °C |
| Shock Resistance | 10 g half-sine wave for 11 ms |
| Vibration Resistance | 1 mm peak to peak (2-13.2 Hz); 0.7 g (13.2-150 Hz) |
| Airborne Contaminants | ISA-S71.04 –1985 Class G3 |
| Relative Humidity | 5 to 95% Non-Condensing |
| Dimensions | 107 x 41 x 105 mm |
| Weight | 0.2 kg |
| Terminal Block Key | A1 |
Product Features
- High Accuracy: Ensures precise analog signal conversion for reliable data acquisition.
- Robust Design: Built to withstand extreme temperatures, shock, and vibration.
- Easy Installation: Features a rotary keying system for compatibility with terminal blocks.
- Energy Efficiency: Low power consumption with optimized field circuit design.
- Safety Compliance: Requires power removal before insertion or removal to ensure safety.
Product Advantages
- Reliability: Engineered for continuous operation in demanding industrial environments.
- Flexibility: Supports multiple input configurations for diverse applications.
- Compatibility: Seamlessly integrates with the DeltaV control system.
- Maintenance-Friendly: Simplified removal and insertion process reduces downtime.
Product Applications
- Process Control: Monitoring and controlling industrial processes.
- Manufacturing: Real-time data acquisition for production lines.
- Oil & Gas: Reliable performance in extreme conditions.
- Power Generation: Accurate signal processing for energy management.
- Water Treatment: Ensuring precise measurement and control.
Latest News Headline
“Emerson Enhances DeltaV System with KJ3222X1-BA1 Analog Input Module for Improved Industrial Automation”
Recommended Related Models
DeltaV Series
| Model | Description | Key Parameters |
|---|---|---|
| KJ3222X1-BB1 | Analog Input Module (Enhanced) | 16 Channels, 24 VDC, 0.25 kg |
| KJ3222X1-BC1 | Analog Input Module (High Density) | 32 Channels, 12 VDC, 0.3 kg |
| KJ3222X1-BD1 | Analog Input Module (Isolated) | 8 Channels, 24 VDC, 0.22 kg |
| KJ3222X1-BE1 | Analog Input Module (Low Power) | 16 Channels, 12 VDC, 0.18 kg |
| KJ3222X1-BF1 | Analog Input Module (High Speed) | 16 Channels, 24 VDC, 0.28 kg |
| KJ3222X1-BG1 | Analog Input Module (Temperature) | 8 Channels, 24 VDC, 0.2 kg |
Popular Emerson Models
| Model | Description | Key Parameters |
|---|---|---|
| KJ3001X1-BA1 | Digital Input Module | 16 Channels, 24 VDC, 0.25 kg |
| KJ3002X1-BA1 | Digital Output Module | 16 Channels, 24 VDC, 0.26 kg |
| KJ4001X1-BA1 | Communication Module | Ethernet, 12 VDC, 0.3 kg |
| KJ5001X1-BA1 | Power Supply Module | 24 VDC, 5 A, 0.4 kg |
| KJ6001X1-BA1 | Safety Module | SIL3 Certified, 0.28 kg |
| KJ7001X1-BA1 | HART Protocol Module | 8 Channels, 24 VDC, 0.22 kg |
FAQ
FAQ
Q1: What is the operating temperature range of the KJ3222X1-BA1?
A1: The module operates reliably in temperatures ranging from -40 °C to +70 °C.
Q2: Can the module be hot-swapped?
A2: No, field power must be removed before inserting or removing the module.
Q3: What is the purpose of the rotary keying system?
A3: It ensures compatibility between I/O cards and terminal blocks, preventing incorrect installations.
Q4: How many channels does the module support?
A4: The module supports multiple channels, with each channel drawing 30 mA at 24 VDC.
Q5: Is the module resistant to vibration?
A5: Yes, it can withstand vibrations of 1 mm peak to peak (2-13.2 Hz) and 0.7 g (13.2-150 Hz).
Q6: What are the dimensions and weight of the module?
A6: The module measures 107 x 41 x 105 mm and weighs 0.2 kg.
Q7: What standards does the module comply with for airborne contaminants?
A7: It complies with ISA-S71.04 –1985 Airborne Contaminants Class G3.
Q8: Can the module be used in humid environments?
A8: Yes, it operates in relative humidity levels of 5 to 95% (non-condensing).
