Product Overview: Bently Nevada 3500/15-04-04-00 133292-01 Legacy Low Voltage DC Power Supply Module
The Bently Nevada 3500/15-04-04-00 133292-01 Legacy Low Voltage DC Power Supply Module is designed for use in the Bently Nevada 3500 Machinery Protection System, offering reliable low voltage DC power for various system modules. It is part of a modular power supply architecture that enables redundancy, making it highly reliable in industrial environments. This power supply module supports a wide input voltage range, ensuring compatibility with different power systems.
Product Parameters:
| Parameter | Value |
|---|---|
| Model | 3500/15-04-04-00 133292-01 |
| Input Voltage | 20 to 30 Vdc |
| Full Rack Current Draw | 11.0 A (maximum) |
| Dimensions (H x W x D) | 120.7 x 50.8 x 251.5 mm |
| Weight | 1.39 kg |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 95%, non-condensing |
| Compliance | FCC, EMC, ATEX, IECEx, RoHS |
| Certification | Class I, Zone 2, T4 |
| Rack Slot Requirements | Two half-height slots |
Product Features:
-
Compact Design: The module’s small footprint allows for easy integration into the 3500 rack, occupying only half-height slots.
-
Redundant Power: The 3500/15 power supply supports redundancy. If two power supplies are installed, one acts as the primary while the other serves as a backup.
-
Wide Input Voltage Range: It operates with input voltages from 20V to 30V DC, providing flexibility in different installation scenarios.
-
Reliability: The system is designed to operate without interruption, even when swapping modules in and out of the rack.
-
Front Panel LEDs: Indicates operational status, simplifying diagnostics and monitoring.
Product Advantages:
-
Redundancy for Continuous Operation: The redundant power supply design ensures that the system continues to operate even if one module fails.
-
High Compatibility: It is compatible with the Bently Nevada 3500 system, making it a reliable choice for a wide range of machinery protection applications.
-
Easy Installation: With its simple design, the power supply module can be quickly integrated into the existing system without disrupting operations.
-
Environmental Resistance: With a wide operating temperature range and high humidity tolerance, this power supply module is suitable for demanding industrial environments.
Product Applications:
The Bently Nevada 3500/15-04-04-00 133292-01 Legacy Low Voltage DC Power Supply Module is primarily used in:
-
Industrial Automation Systems: Supporting machinery protection and condition monitoring systems.
-
Power Generation: Used in power plants to monitor and protect critical machinery.
-
Oil and Gas: Applied in both onshore and offshore oil platforms where reliable power supply is essential for safety systems.
-
Process Industries: Ensuring continuous monitoring of critical assets in environments where failure is not an option.
Latest Reports:
-
Report on Bently Nevada’s Continued Growth in Industrial Protection Systems
-
Bently Nevada Enhances Power Supply Systems for Critical Applications
-
New Innovations in Low Voltage DC Power Supply for Machinery Protection
-
Field Tests Showcase Improved Reliability of 3500 Series Power Supplies
Related Bently Nevada Models:
| Model | Description | Input Voltage | Rack Slot Requirements | Dimensions (H x W x D) |
|---|---|---|---|---|
| 3500/15-03 | High Voltage DC Power Supply | 88 to 140 Vdc | Half-height slot | 120.7 x 50.8 x 251.5 mm |
| 3500/15-06 | High Voltage DC Power Supply (Standard) | 88 to 140 Vdc | Half-height slot | 120.7 x 50.8 x 251.5 mm |
| 3500/15-07 | Low Voltage DC Power Supply | 20 to 30 Vdc | Half-height slot | 120.7 x 50.8 x 251.5 mm |
| 3500/15-05 | Universal AC Power Supply | 85 to 264 Vac | Half-height slot | 120.7 x 50.8 x 251.5 mm |
| 3500/15-04 | Legacy Low Voltage DC Power Supply | 20 to 30 Vdc | Half-height slot | 120.7 x 50.8 x 251.5 mm |
| 3500/15-02 | Universal AC Power Input Module | 85 to 264 Vac | Half-height slot | 120.7 x 25.4 x 114.3 mm |
Popular Bently Nevada Models:
| Model | Description | Input Voltage | Full Rack Current Draw | Dimensions (H x W x D) |
|---|---|---|---|---|
| 3500/22M | Machinery Protection Module | 20 to 30 Vdc | 11.0 A (maximum) | 120.7 x 50.8 x 251.5 mm |
| 3500/40M | Vibration Monitoring System | 20 to 30 Vdc | 11.0 A (maximum) | 120.7 x 50.8 x 251.5 mm |
| 3500/23B | Pressure Monitoring Module | 20 to 30 Vdc | 11.0 A (maximum) | 120.7 x 50.8 x 251.5 mm |
| 3500/11M | Machinery Protection Module | 20 to 30 Vdc | 11.0 A (maximum) | 120.7 x 50.8 x 251.5 mm |
| 3500/25M | Temperature Monitoring Module | 20 to 30 Vdc | 11.0 A (maximum) | 120.7 x 50.8 x 251.5 mm |
| 3500/15-04 | Legacy Low Voltage DC Power Supply Module | 20 to 30 Vdc | 11.0 A (maximum) | 120.7 x 50.8 x 251.5 mm |
FAQ
FAQs:
Q1: What input voltage range does the Bently Nevada 3500/15-04-04-00 support?
A1: The module supports an input voltage range of 20 to 30 Vdc.
Q2: How much current does the 3500/15-04-04-00 module draw from the full rack?
A2: The module draws a maximum of 11.0 A from the full rack.
Q3: What are the dimensions of the 3500/15-04-04-00 power supply module?
A3: The dimensions are 120.7 x 50.8 x 251.5 mm (H x W x D).
Q4: What is the operating temperature range for this power supply?
A4: The operating temperature range is from -30°C to +65°C.
Q5: Can I use this power supply module in hazardous environments?
A5: Yes, it is certified for use in hazardous environments with Class I, Zone 2, T4 ratings.
Q6: How does the redundancy feature work in the 3500/15 system?
A6: If two power supplies are installed, one acts as the primary supply and the other as a backup. This ensures continued operation if one module fails.
Q7: What certifications does the 3500/15-04-04-00 power supply module have?
A7: It is certified under FCC, EMC, ATEX, IECEx, and RoHS.
Q8: Can the 3500/15-04-04-00 module be installed without any minimum load?
A8: Yes, there is no minimum load requirement for this module.
