Technical Specifications
| Parameter | Specification |
|---|---|
| Article Number | 3BSE066485R1 |
| Processor Type | MPC860 |
| Clock Frequency | 24 MHz |
| Performance (1000 boolean operations) | 0.46 ms |
| Memory | 12 MB |
| RAM Available for Application | 6.253 MB |
| Flash Memory for Storage | Yes |
| Number of Applications per Controller | 32 |
| Number of Programs per Application | 64 |
| Number of Diagrams per Application | 128 |
| Number of Tasks per Controller | 32 |
| Cycle Time per Application Programs | Down to 1 ms |
| Flash PROM for Firmware Storage | 2 MB |
| Power Supply | 24 V DC (19.2-30 V DC) |
| Power Consumption | 180 mA typ, 300 mA max |
| Power Dissipation | 4.32 W (7.2 W max) |
| Built-in Back-up Battery | Lithium, 3.6 V |
| Clock Synchronization | 1 ms between AC 800M controllers by CNCP protocol |
| Redundant Power Supply Status Input | Yes |
| RS-232C Interfaces | 2 (One general, One for service tool) |
| Ethernet Interface | Ethernet (IEEE 802.3), 10 Mbit/s, RJ-45, female |
| Real-time Clock Stability | 100 ppm (approx. 1 hour/year) |
| Operating Temperature | +5 to +55 °C |
| Storage Temperature | -40 to +70 °C |
| Relative Humidity | 5 to 95 %, non-condensing |
| Protection Class | IP20 |
| Weight | 1.1 kg (including base) |
| Dimensions (W x H x D) | 119 x 186 x 135 mm |
FAQ
FAQ
-
Q: What is the processor type used in the PM851AK01?
A: The PM851AK01 uses the MPC860 processor. -
Q: What is the power supply voltage range for the PM851AK01?
A: The power supply voltage range is 24 V DC (19.2-30 V DC). -
Q: How much RAM is available for application use on the PM851AK01?
A: The PM851AK01 provides 6.253 MB of RAM for application use. -
Q: What is the maximum number of applications supported by the PM851AK01?
A: The PM851AK01 supports up to 32 applications. -
Q: What is the cycle time per application for the PM851AK01?
A: The cycle time per application program can be as low as 1 ms. -
Q: What temperature range is the PM851AK01 designed to operate in?
A: The PM851AK01 can operate in temperatures ranging from +5 to +55 °C. -
Q: How many Ethernet ports does the PM851AK01 have?
A: The PM851AK01 has 1 Ethernet port. -
Q: What is the weight of the PM851AK01 controller?
A: The weight of the PM851AK01 controller, including its base, is 1.1 kg.
