Technical Specifications
| Parameter | Details |
|---|---|
| Model Number | PM510V16 |
| Part Number | 3BSE008358R1 |
| Memory Capacity | 16 MB total (approx. 11 MB available for application) |
| Redundancy Support | Yes, supports 1-to-1 redundancy scheme |
| Communication | High-speed link for redundancy synchronization |
| Power Consumption (Typical) | 5.0 A @ 5 VDC, 1.49 A @ 24 VDC |
| Cooling Load | 208 BTU/H (Typical) |
| Mounting | Subrack mounted (AC460 system) |
| Application Compatibility | S100 I/O, S800 I/O, TRIO LAN, MOD300 DCN |
| Dimensions (W × H × D) | 477 × 22.5 × 261 mm |
| Weight | 0.875 kg |
| System Software Requirements | Requires AdvaControl Basic Software License |
| Application RAM Usage Estimate | Based on control loops, trends, TCL/FCM objects |
| Part of System | Advant Controller 460 |
| Upgrade Option | MB540 Kit – converts from PM510V08 to PM510V16 |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main difference between PM510V08 and PM510V16?
A1: The PM510V16 offers 16 MB RAM, double that of PM510V08. This allows for larger or more complex control applications.
Q2: Can the PM510V16 module be used in redundant configurations?
A2: Yes. It supports full processor redundancy with automatic switchover in approximately 25 milliseconds upon failure detection.
Q3: How much memory is actually available for user application programming?
A3: Approximately 11 MB of the 16 MB RAM is available for user applications such as CCF loops, trends, and TCL logic.
Q4: Is a software license needed for the PM510V16 to operate?
A4: Yes. An AdvaControl Basic Software License is required for each processor module (or redundant pair), along with any necessary incremental licenses based on I/O count.
Q5: What types of I/O systems can the PM510V16 interact with?
A5: It supports S100 I/O, S800 I/O, and TRIO Fieldbus systems, making it flexible for various field interfaces.
Q6: What kind of physical environment does the module require?
A6: It is designed for cabinet-mounted industrial environments, typically in Advant RM5xx cabinet systems with suitable cooling and power supplies.
Q7: Is the module hot-swappable during operation?
A7: In a redundant configuration, the failed processor can be safely removed and replaced without shutting down the system.
Q8: How do I upgrade from PM510V08 to PM510V16?
A8: ABB provides an upgrade kit (MB540) that converts a PM510V08 to a PM510V16, enabling increased memory without full hardware replacement.
