— Product Overview: ABB DSBC 173 57310001-KH Bus Repeater Slave Module
The ABB DSBC 173 (57310001-KH) is a slave unit in the Bus Repeater family designed for use within ABB’s Advant Controller 400 series and is particularly integral to the MasterBus 300 system. It enables the extension of the I/O system and supports long-distance communication by interfacing remote and local bus segments effectively. The module functions as a slave to the DSBC 172 Master Repeater Module, forming a crucial part of a distributed control network with high reliability and stability.
It is engineered for industrial automation systems that require decentralized control architectures with real-time responsiveness, supporting seamless integration into ABB’s control platforms.
— Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | Bus Repeater Slave Module |
| Model Number | DSBC 173 |
| Order Code | 57310001-KH |
| Type | Slave Repeater Module for MasterBus 300 |
| Interface | For use with DSBC 172 |
| Mounting | DIN rail or mounting plate |
| Power Supply | 5 V DC supplied via Bus |
| Operating Temperature | 0 to +60 °C |
| Storage Temperature | -40 to +70 °C |
| Relative Humidity | 5% to 95% non-condensing |
| EMC Compliance | Meets IEC standards |
| System Compatibility | Advant Controller 400, MasterBus 300 |
| Dimensions (W x H x D) | 360 x 20 x 260 mm |
| Weight | 0.33 kg |
| Redundancy Support | No (Slave functionality only) |
| Diagnostics | LED Indicators |
| Module Type | Communication Interface Module |
— Product Features
-
Functions as a slave bus repeater in MasterBus 300 network.
-
Communicates with DSBC 172 Master Module for segmented network setups.
-
Ensures signal integrity over long distances.
-
LED indicators for status diagnostics.
-
Plug-in module design ensures easy installation and maintenance.
-
DIN rail mountable for standardized integration.
-
Supports isolation between segments to reduce noise and faults.
-
Designed for harsh industrial environments with wide operating temperature range.
— Product Advantages
-
Reliable communication between control modules over extended distances.
-
Compact form factor fits easily into crowded control cabinets.
-
Reduces the need for multiple cables by extending bus segments.
-
Facilitates remote I/O placement, enhancing flexibility in system architecture.
-
Cost-effective solution for expanding MasterBus 300 networks.
-
Integrated LED indicators help in quick diagnostics and maintenance.
— Product Applications
-
Power generation plants
-
Oil and gas refineries
-
Chemical processing facilities
-
Pharmaceutical automation systems
-
Pulp and paper industry
-
Water and wastewater treatment
-
Steel and mining operations
-
Advanced manufacturing control systems
The DSBC 173 module is typically installed in remote I/O cabinets connected via bus repeaters in systems using ABB’s Advant Controller 400 series.
— Latest Product-Related News Headline
“ABB Extends Lifecycle Support for Advant Controller 400 Series Components Including DSBC 173 Bus Repeater”
— Related Models from the Same Series
| Model Number | Description | Role | Dimensions (mm) | Weight |
|---|---|---|---|---|
| DSBC 172 | Bus Repeater Master Module | Master | 360 x 20 x 260 | 0.34 kg |
| DSBC 111 | Bus Extension Module | Communication | 360 x 20 x 260 | 0.33 kg |
| DSAI 130 | Analog Input Module | I/O Module | 360 x 20 x 260 | 0.30 kg |
| DSAO 120 | Analog Output Module | I/O Module | 360 x 20 x 260 | 0.32 kg |
| DSDI 110 | Digital Input Module | I/O Module | 360 x 20 x 260 | 0.28 kg |
| DSDO 115 | Digital Output Module | I/O Module | 360 x 20 x 260 | 0.29 kg |
— Popular ABB Models Across Systems
| Model Number | Description | Application Area | Dimensions (mm) | Weight |
|---|---|---|---|---|
| AI835 | Analog Input Module (S800 I/O) | Distributed Control Systems | 59.1 x 216 x 128 | 0.21 kg |
| CI854A | Profibus DP-V1 Interface Module | Communication Interface | 59.1 x 216 x 128 | 0.18 kg |
| PM864AK01 | AC 800M CPU Module | Central Controller | 186 x 59 x 139 | 0.39 kg |
| TU810V1 | Terminal Unit for S800 Modules | Field Wiring Interface | 134.5 x 45 x 135 | 0.14 kg |
| DI810 | Digital Input Module (24VDC) | Signal Acquisition | 59.1 x 216 x 128 | 0.23 kg |
| DO820 | Digital Output Module (24VDC/0.5A) | Signal Output | 59.1 x 216 x 128 | 0.25 kg |
FAQ
— Frequently Asked Questions (FAQ)
Q1: What is the primary function of the DSBC 173 module?
A1: The DSBC 173 operates as a slave in a bus repeater pair, enabling extension of the MasterBus 300 communication bus and supporting remote I/O communications.
Q2: Is DSBC 173 compatible with all ABB controllers?
A2: No, DSBC 173 is specifically designed for use with ABB Advant Controller 400 series and must pair with a DSBC 172 master module.
Q3: Can DSBC 173 be used alone without DSBC 172?
A3: No, DSBC 173 requires a corresponding DSBC 172 master module to function properly.
Q4: What is the mounting method for DSBC 173?
A4: It is designed for standard DIN rail or plate mounting inside control cabinets.
Q5: Does the module support diagnostics?
A5: Yes, it has LED indicators for communication and fault status monitoring.
Q6: What environments is DSBC 173 suitable for?
A6: It is ideal for harsh industrial environments, with wide temperature and humidity tolerance.
Q7: Can DSBC 173 extend the bus over long distances?
A7: Yes, its repeater functionality enables long-distance communication between control and I/O units.
Q8: Is the DSBC 173 module hot-swappable?
A8: No, it should only be installed or removed when the system is powered down to ensure safety and avoid data loss.
