Product Description
The ABB DP620 3BHT300016R1 is a high-speed counter module designed for industrial automation applications requiring precise and rapid counting of digital signals. It supports 5 input channels with a counting speed of up to 100 kHz, making it ideal for high-performance monitoring and control tasks. The module operates on 5/24V DC and is part of ABB’s extensive I/O module portfolio, ensuring seamless integration into existing automation systems.
Product Specifications
| Parameter | Specification |
|---|---|
| Product Type | I/O Module (Digital Input) |
| Model Number | DP620 3BHT300016R1 |
| Channel Type | Digital Input (DI) |
| Number of Channels | 5 |
| Counting Speed | Up to 100 kHz |
| Supply Voltage | 5/24V DC |
| Dimensions (W×H×D) | 252 × 273 × 40 mm |
| Weight | 1.635 kg |
| Operating Temperature | -20°C to +70°C |
| Protection Class | IP20 (Standard industrial enclosure) |
| Communication Interface | Backplane bus integration |
| Mounting | DIN rail or panel mounting |
| Certifications | CE, UL, IEC standards compliant |
Key Features
- High-Speed Counting: Capable of processing signals up to 100 kHz, ensuring accurate counting in demanding applications.
- Multiple Input Channels: Provides 5 independent digital input channels for versatile signal acquisition.
- Wide Voltage Range: Supports both 5V and 24V DC inputs, enhancing compatibility with various sensors and devices.
- Robust Design: Compact and durable construction with IP20 protection, suitable for industrial environments.
- Easy Integration: Compatible with ABB’s automation systems, allowing seamless incorporation into control architectures.
Advantages
✔ High Precision: Ensures reliable counting even at high frequencies.
✔ Flexibility: Works with multiple voltage levels, reducing the need for additional signal conditioning.
✔ Space-Efficient: Compact form factor saves cabinet space.
✔ Industrial-Grade Reliability: Built to withstand harsh conditions with extended operational life.
✔ Compliance with Standards: Meets CE, UL, and IEC certifications for safety and performance.
Applications
- Manufacturing Automation: High-speed production line monitoring.
- Packaging Machinery: Counting products, labels, or fill levels.
- Motion Control Systems: Encoder feedback processing.
- Energy Management: Pulse counting for flow meters and energy monitoring.
- Material Handling: Conveyor belt speed and position tracking.
Latest News Headline
“ABB Expands High-Speed Counter Module Lineup with Enhanced DP620 Series for Industrial Automation”
Recommended Related/Alternative Models
ABB DP Series High-Speed Counters & I/O Modules
| Model | Channels | Max Frequency | Voltage | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| DP620 3BHT300016R1 | 5 DI | 100 kHz | 5/24V DC | 252 × 273 × 40 | 1.635 |
| DP640 3BHT300017R1 | 8 DI | 200 kHz | 24V DC | 252 × 273 × 40 | 1.8 |
| DP660 3BHT300018R1 | 16 DI | 50 kHz | 5/24V DC | 300 × 273 × 40 | 2.1 |
| DP680 3BHT300019R1 | 4 DI + 4 DO | 100 kHz (DI) | 24V DC | 252 × 273 × 40 | 1.7 |
| DP700 3BHT300020R1 | 32 DI | 10 kHz | 24V DC | 300 × 273 × 40 | 2.5 |
| DP720 3BHT300021R1 | 8 DI (Isolated) | 500 kHz | 5/24V DC | 252 × 273 × 40 | 1.9 |
Recommended ABB High-Speed Counter & I/O Modules
| Model | Type | Channels | Max Frequency | Voltage | Dimensions (mm) | Weight (kg) | Key Features |
|---|---|---|---|---|---|---|---|
| DP620 3BHT300016R1 | High-Speed Counter | 5 DI | 100 kHz | 5/24V DC | 252 × 273 × 40 | 1.635 | Compact, multi-voltage input |
| DP640 3BHT300017R1 | High-Speed Counter | 8 DI | 200 kHz | 24V DC | 252 × 273 × 40 | 1.8 | Higher channel count & speed |
| DP660 3BHT300018R1 | Digital Input Module | 16 DI | 50 kHz | 5/24V DC | 300 × 273 × 40 | 2.1 | High-density inputs |
| DP680 3BHT300019R1 | Mixed I/O Module | 4 DI + 4 DO | 100 kHz (DI) | 24V DC | 252 × 273 × 40 | 1.7 | Combined digital I/O |
| DP720 3BHT300021R1 | Isolated High-Speed Counter | 8 DI | 500 kHz | 5/24V DC | 252 × 273 × 40 | 1.9 | Isolated inputs for noise immunity |
| DP700 3BHT300020R1 | Bulk Digital Input | 32 DI | 10 kHz | 24V DC | 300 × 273 × 40 | 2.5 | Large-scale input monitoring |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum counting frequency of the DP620 module?
A1: The DP620 supports counting up to 100 kHz per channel.
Q2: Can this module work with both 5V and 24V sensors?
A2: Yes, it is compatible with 5V and 24V DC input signals.
Q3: What are the mounting options for the DP620?
A3: It can be mounted on a DIN rail or panel-mounted for flexible installation.
Q4: Is the DP620 suitable for harsh industrial environments?
A4: Yes, it has an IP20 protection rating and operates within -20°C to +70°C.
Q5: How many input channels does the DP620 have?
A5: It features 5 digital input channels.
Q6: What certifications does the DP620 comply with?
A6: It meets CE, UL, and IEC standards for industrial safety.
Q7: Can the DP620 be integrated with ABB’s PLC systems?
A7: Yes, it is designed for seamless integration with ABB automation systems.
Q8: What is the weight and dimensions of the DP620?
A8: It measures 252 × 273 × 40 mm and weighs 1.635 kg.
