Technical Specifications
| Parameter | Value |
|---|---|
| Article Number | 3BSE018106R1 |
| Communication Protocol | ABB MasterBus 300 |
| Master/Slave | Master |
| Transmission Speed | 10 Mbit/s, 200 Datasets/s |
| Line Redundancy | Yes |
| Module Redundancy | No |
| Hot Swap | Yes |
| Max Units on CEX Bus | 12 |
| Connector | RJ-45 female (8-pin) |
| Typical Power Consumption | 150 mA @ 24 V |
| Operating Temperature | +5 to +55 °C (+41 to +131 °F) |
| Storage Temperature | -40 to +70 °C (-40 to +158 °F) |
| Corrosion Protection | G3 compliant |
| Protection Class | IP20 (IEC 529, EN 60529) |
| CE Marking | Yes |
| Marine Certificates | BV, DNV-GL, LR |
| RoHS Compliance | Yes |
| WEEE Compliance | Yes |
| Dimensions | 127.5 x 186 x 59 mm |
| Weight | 700 g (1.5 lbs) |
FAQ
FAQ
Q1: What communication protocols does the ABB CI855K01 module support?
A1: The ABB CI855K01 supports the ABB MasterBus 300 communication protocol.
Q2: Does the ABB CI855K01 module support hot swap?
A2: Yes, the ABB CI855K01 module supports hot swap functionality.
Q3: What is the maximum number of units that can be connected to the ABB CI855K01 module?
A3: The module supports up to 12 units connected.
Q4: What is the operating temperature range of the ABB CI855K01 module?
A4: The operating temperature range of the ABB CI855K01 is +5°C to +55°C (+41°F to +131°F).
Q5: Is the ABB CI855K01 module compliant with RoHS and WEEE standards?
A5: Yes, the ABB CI855K01 module is compliant with both RoHS and WEEE directives.
Q6: What are the dimensions of the ABB CI855K01 module?
A6: The dimensions of the ABB CI855K01 are 127.5 x 186 x 59 mm.
Q7: What is the weight of the ABB CI855K01 module?
A7: The weight of the ABB CI855K01 module is 700 g (1.5 lbs).
Q8: Does the ABB CI855K01 module support master-slave communication?
A8: Yes, the ABB CI855K01 module operates as a master device.
