Technical Specifications
| Parameter | Details |
|---|---|
| Module Type | Digital Output Module |
| Output Channels | 16 |
| Output Type | Open Collector |
| Output Voltage Range | 0–30 VDC |
| Output Current per Channel | Up to 100 mA |
| Isolation | Channel-to-logic and channel-to-channel |
| Logic Side Supply Voltage | 5 VDC (nominal) |
| Field Side Power Supply | 24 VDC (nominal) |
| Channel Status Indicators | Yes (LED indicators for each output) |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | DIN Rail / Panel Mount |
| Compatible System | Bailey INFI 90 |
| Dimensions (W x H x D) | 73.66 x 360.68 x 279.4 mm |
| Weight | 0.25 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the SPDSO14 module?
A1: The SPDSO14 is designed to provide 16 open collector digital outputs for interfacing with field devices that require discrete control.
Q2: What kind of loads can the SPDSO14 control?
A2: It is suitable for low-current DC loads such as relays, solenoids, and signal lamps operating within the 0–30 VDC range.
Q3: Does the module support channel-to-channel isolation?
A3: Yes, the SPDSO14 includes channel-to-channel and channel-to-logic isolation for enhanced protection and signal integrity.
Q4: Can I monitor the output status of each channel?
A4: Yes, each channel has an LED indicator that shows the current status of the output, making diagnostics easier.
Q5: Is the SPDSO14 hot-swappable?
A5: No, the module should not be inserted or removed while the system is powered to avoid damage or malfunction.
Q6: What is the maximum current that each output channel can handle?
A6: Each output channel can handle up to 100 mA of current, which is sufficient for most control applications in process systems.
Q7: Which control system is the SPDSO14 compatible with?
A7: This module is specifically designed for use with ABB Bailey’s INFI 90 process control system.
Q8: How should the module be mounted for optimal performance?
A8: It can be mounted on a DIN rail or panel-mounted, ensuring adequate ventilation and accessibility for wiring and maintenance.
