roduct Overview: ABB Bailey NTCF23 INFI-Net Optic-to-Electric Termination Unit
The ABB Bailey NTCF23 is a high-performance INFI-Net Electric-to-Optic Termination Unit designed for use within the Infi 90 Distributed Control System (DCS). It provides critical communication conversion from electrical signals to optical transmission, enabling long-distance and high-integrity data exchange over fiber optic networks. Installed at the interface of control systems and fiber optic networks, this unit ensures stable, high-speed communication across large industrial facilities.
This unit is a key component in modernizing plant communication infrastructure, offering a reliable bridge between legacy electric transmission lines and high-speed fiber optic links.
Technical Specifications of NTCF23
| Parameter | Specification |
|---|---|
| Product Name | ABB Bailey NTCF23 |
| Product Type | Electric-to-Optic Termination Unit |
| Communication Protocol | INFI-Net |
| Signal Conversion | Electric to Fiber Optic |
| Compatible System | INFI 90 DCS |
| Dimensions (W x H x D) | 160.02 x 228.6 x 213.36 mm |
| Weight | 0.65 kg |
| Installation | DIN rail or chassis-mounted |
| Power Supply | 24 VDC nominal (from system chassis) |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Humidity | 5%–95% non-condensing |
| Fiber Optic Interface | ST-type connectors |
| Electric Interface | Shielded Twisted Pair (STP) |
| Status Indicators | LED indicators for Power and Communication |
| Certifications | CE, UL, CSA (depending on model origin) |
Key Features
-
Converts INFI-Net electrical signals to fiber optic signals with precision.
-
Enables long-distance communication free from electromagnetic interference (EMI).
-
Enhances noise immunity in noisy industrial environments.
-
Compact design with robust housing suitable for industrial applications.
-
Easy integration with existing INFI 90 DCS architecture.
-
LED indicators for status monitoring and troubleshooting.
-
Plug-and-play replacement in existing systems.
-
Designed for extended life and minimal maintenance.
Product Advantages
-
Reliability: Operates with high consistency in critical process control networks.
-
Extended Communication Distance: Fiber optics enable significantly longer distances than copper.
-
Noise Immunity: Immune to EMI and RFI, ensuring signal integrity.
-
Scalability: Seamless integration into larger or expanding DCS networks.
-
Reduced Downtime: High reliability reduces maintenance intervention.
-
Industrial Compliance: Adheres to safety and performance standards for harsh industrial environments.
Applications
-
Large-scale process industries requiring robust communication networks
-
Power generation plants integrating fiber optic communication
-
Oil and gas facilities with high EMI environments
-
Chemical and pharmaceutical manufacturing plants
-
Water and wastewater treatment plants
-
Refineries using legacy Bailey INFI 90 systems needing modernization
-
Pulp and paper industry with centralized control and remote I/O
Latest Reports and Product Updates (Headline Examples)
-
“ABB Expands Support for Legacy INFI 90 Systems with Enhanced NTCF23 Termination Units”
-
“Fiber-Optic Communication Boosts Reliability in Bailey Control Networks”
-
“ABB Bailey NTCF23 Helps Extend System Lifespan in Industrial Upgrades”
-
“ABB Focuses on Modernizing INFI-Net Architecture with NTCF23 Fiber Units”
-
“Refinery Reduces Signal Interference with ABB NTCF23 Optical Conversion”
-
“Bailey Systems Maintain Performance with ABB NTCF23 Electric-to-Optic Upgrade”
Related Models (Same Series or Functionally Similar)
| Model | Description | Dimensions (mm) | Weight | Function |
|---|---|---|---|---|
| NTCF01 | INFI-Net Electric-to-Electric Termination Unit | 160.02 x 228.6 x 213.36 | 0.60 kg | Electrical signal termination |
| NTCF02 | INFI-Net Electric-to-Electric TU, High EMI Resistant | 160.02 x 228.6 x 213.36 | 0.62 kg | Enhanced EMI protection |
| NTCF12 | Electric-to-Fiber for Local Loop Communications | 160.02 x 228.6 x 213.36 | 0.64 kg | Local INFI-Net optic link |
| NTCF20 | Fiber Optic to Electric Conversion Unit | 160.02 x 228.6 x 213.36 | 0.63 kg | Optic-to-Electric TU |
| NTCF24 | Fiber Termination Unit with Dual Fiber Channels | 160.02 x 228.6 x 213.36 | 0.66 kg | Redundant fiber path handling |
| INNIS21 | Network Interface Module for INFI-Net | 160.02 x 228.6 x 213.36 | 0.68 kg | Central network data routing |
Popular ABB Bailey Models
| Model | Description | Dimensions (mm) | Weight | Application |
|---|---|---|---|---|
| INNPM22 | Network Processing Module | 160.02 x 228.6 x 213.36 | 0.75 kg | INFI-Net processor |
| IMMFP12 | Multi-Function Processor Module | 160.02 x 228.6 x 213.36 | 0.72 kg | Control processing |
| INFI90/IMFCS | Controller Submodule for INFI-Net Systems | 160.02 x 228.6 x 213.36 | 0.78 kg | Logic and control functionality |
| INNIS11 | Network Interface Slave Module | 160.02 x 228.6 x 213.36 | 0.68 kg | Distributed I/O interface |
| INICT03A | Communication Interface Module | 160.02 x 228.6 x 213.36 | 0.70 kg | PC to INFI-Net communication |
| IMASI23 | Analog Input Module | 160.02 x 228.6 x 213.36 | 0.69 kg | High-density AI module |
FAQ
FAQ – ABB Bailey NTCF23
Q1: What does the NTCF23 module do?
A1: The NTCF23 converts INFI-Net electrical signals into fiber optic signals for long-distance, interference-free communication.
Q2: Is the NTCF23 compatible with all INFI 90 systems?
A2: Yes, it is specifically designed for use in ABB Bailey INFI 90 Distributed Control Systems.
Q3: What type of fiber connectors does it support?
A3: The unit supports ST-type fiber optic connectors.
Q4: Can I use the NTCF23 in high EMI environments?
A4: Yes, the fiber optic design inherently eliminates susceptibility to EMI/RFI interference.
Q5: Is the module hot-swappable?
A5: It is recommended to power down the system before replacement to ensure communication stability.
Q6: How is the NTCF23 mounted?
A6: The unit is typically mounted within the system chassis or on a DIN rail, depending on cabinet configuration.
Q7: What are the visual indicators on the unit?
A7: The NTCF23 includes LED indicators for power status and communication activity.
Q8: What is the typical weight and size of the NTCF23?
A8: The unit measures 160.02 x 228.6 x 213.36 mm and weighs approximately 0.65 kg.
