ABB Bailey NIAI02 Infi 90 Analog Input Termination Module

ABB Bailey NIAI02 Infi 90 Analog Input Termination Module

Manufacturer:Bailey

Product Number:NIAI02

Product Type:Analog Input Termination Module

Origin:Sweden (SE)

Dimensions:120 x 150 x 50 mm

Weight:0.5 kg

Views:20

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.
